1/8
TK12
www.dynexsemi.com
FEATURES
I
High Surge Capability
APPLICATIONS
I
High Power Drives
I
High Voltage Power Supplies
I
DC Motor Control
I
Welding
I
Battery Chargers
VOLTAGE RATINGS
ORDERING INFORMATION
When ordering, select the required part number shown in the
Voltage Ratings selection table, then:-
Add K to type number for 1/2" 20 UNF thread, e.g.
TK12 18K
.
or
Add M to type number for M12 thread, e.g.
TK12 14M
.
Note: Please use the complete part number when ordering and
quote this number in any future correspondance relating to your
order.
KEY PARAMETERS
V
DRM
I
T(AV)
I
TSM
dVdt*
2000V
75A
1400A
200V/
μ
s
500A/
μ
s
dI/dt
*Higher dV/dt selections available
TK12
Phase Control Thyristor
Advance Information
Replaces January 2000 version, DS4252-4.0
DS4252-5.0 July 2001
TK12 20 M or K
TK12 18 M or K
TK12 16 M or K
TK12 14 M or K
Conditions
T
vj
= 0 to 125C,
I
DRM
= I
RRM
= 100mA,
V
DRM
, V
RRM
t
p
= 10ms,
V
DSM
& V
RSM
=
V
& V
+ 100V
Respectively
Lower voltage grades available.
Type Number
Repetitive Peak
Voltages
V
DRM
V
RRM
V
2000
1800
1600
1400
Fig. 1 Package outline
Outline type code: TO94.
See Package Details for further information.
