1999 Aug 26
13
Philips Semiconductors
Product specication
Self Tuned Radio (STR)
TEA5757; TEA5759
CHARACTERISTICS
VCC1 =3V; Tamb =25 °C; unless otherwise specied.
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
VCC1
supply voltage
2.5
12
V
VCC2
supply voltage for tuning
12
V
VDDD
supply voltage for digital part
2.5
12
V
Vtune
tuning voltage
0.7
VCC2 0.75 V
ICC2
supply current for tuning in
preset mode (band-end to
band-end)
800
A
fBUS-CLOCK(max) maximum BUS-CLOCK
frequency
300
kHz
ICC1
current consumption during
acquisition of VCC1
AM mode
12
15
18
mA
FM mode
12.5
15.5
18.5
mA
IDD
current consumption during
acquisition of IDD
AM mode
4.8
mA
FM mode
5.5
mA
ICC1
current consumption after
acquisition of VCC1
AM mode
12
15
18
mA
FM mode
13
16
19
mA
IDD
current consumption after
acquisition of IDD
AM mode
3.3
mA
FM mode
2.7
mA
tsearch
synthesizer auto-search time for
empty band
FM mode
10
s
tacq
synthesizer preset acquisition
time between two band limits
FM
100
ms
MW
100
ms
LW
200
ms
SW
500
ms
fband
frequency band range of the
synthesizer
AM mode
0.144
30
MHz
FM mode
50
150
MHz
f
FM
AFC inaccuracy of FM
1
kHz
f
AM
AFC inaccuracy of AM
100
Hz
IP0(sink)
sink current of software
programmable output P0
V30 =3V
4
6
mA
IP1(sink)
sink current of software
programmable output P1
V31 =3V
4
6
mA
IP0(source)
source current of software
programmable output P0
V30 =0V
5
9
mA
IP1(source)
source current of software
programmable output P1
V31 =0V
5
9
mA
