TEA1761T_2
NXP B.V. 2007. All rights reserved.
Product data sheet
Rev. 02 — 25 April 2007
6 of 13
NXP Semiconductors
TEA1761T
GreenChip synchronous rectier controller
8.
Limiting values
[1]
Equivalent to discharging a 100 pF capacitor through a 1.5 k
series resistor.
[2]
Equivalent to discharging a 200 pF capacitor through a 0.75
H coil and a 10 resistor.
9.
Thermal characteristics
The graph in Figure 4 shows the relationship between junction temperature and VSENSE
voltage.
Table 3.
Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134). All voltages are measured with respect to ground
(pin 2); positive currents ow into the chip. The voltage ratings are valid provided other ratings are not violated; current ratings
are valid provided the other ratings are not violated.
Symbol
Parameter
Conditions
Min
Max
Unit
Voltages
VCC
supply voltage
continuous
0.4
+38
V
VOPTO
voltage on pin OPTO
continuous
0.4
+38
V
VSRSENSE
voltage on pin SRSENSE
continuous
-
120
V
VVSENSE
voltage on pin VSENSE
continuous
0.4
+5
V
VISENSE
voltage on pin ISENSE
0.4
+5
V
Currents
IOPTO
current on pin OPTO
-
12
mA
IDRIVER
current on pin DRIVER
duty cycle < 10 %
0.8
+3
A
ISRSENSE
current on pin SRSENSE
3-
mA
General
Ptot
total power dissipation
Tamb <80 °C
-
0.45
W
Tstg
storage temperature
55
+150
°C
Tj
junction temperature
20
+150
°C
ESD
VESD
electrostatic discharge voltage
class 2
human body model
-
2000
V
machine model
-
200
V
charged device model
-
500
V
Table 4.
Thermal characteristics
Symbol
Parameter
Conditions
Typ
Unit
Rth(j-a)
thermal resistance from junction to ambient
in free air
150
K/W
