1998 Feb 13
48
Philips Semiconductors
Preliminary specification
Digital TV Sound Processor (DTVSP)
TDA9875
Table 44
Description of bit SC1GAIN (note 1)
Note
1.
A possibility to copy from SCART 1 input to SCART 1 output is not implemented.
10.3.18 SCART 2
OUTPUT SELECT REGISTER
10.3.18.1 Description
This register is used to define both the signal source to be output at SCART 2 and the output channel selector mode.
10.3.18.2 Definition
Table 45
Subaddress 21 (notes 1 and 2)
Notes
1.
2.
3.
X = don’t care.
The default setting at power-up is 00000000.
See Table 48.
Table 46
Signal source
Table 47
Bits B5 and B4
NAME
HIGH/LOW
FUNCTION
SC1GAIN
HIGH
Activates the 3 dB gain stage at the SCART 1 output port. As any SCART input passes
a 3 dB attenuator, this gain stage can be used to compensate that attenuation, resulting
in a 0 dB insertion loss when copying from SCART 2 input to SCART 1 output.
However, that gain must be used with great care, as it will cause signal clipping at high
input levels.
The audio signal will be output unchanged (0 dB gain).
LOW
MSB
LSB
B7
X
B6
B5
B4
B3
X
B2
B1
B0
SC2GAIN
(3)
see Table 47
see Table 46
B2
B1
B0
SIGNAL SOURCE
0
0
0
1
0
1
1
0
0
0
1
0
SCART 1 input
external input
mono input
DAC input
B5
B4
L OUTPUT
R OUTPUT
0
0
1
1
0
1
0
1
L input
L input
R input
R input
R input
L input
R input
L input
