TB2905HQ
2006-04-28
5
4.
Offset Detection Function
Pin 25 can be used to detect an offset voltage that may appear on an output pin due to input capacitor
leakage or other reasons.
Output DC
voltage (
+)
Offset detection threshold
(RS1 detection)
VCC/2
(normal DC voltage)
GND
Time
GND
Voltage at point A
(output of pin 25)
Voltage at point B
(LPF output)
Offset detection threshold
(RS2 detection)
Time
RS2
Figure 6
Example application and detection mechanism
Vref
Electrical
volume
25
5 V
L.P.F.
smoothing
circuit
To microcontroller The
microcontroller shuts down the
system if the output is lower than
the specified voltage.
+
V
Output offset voltage
(upon input capacitor leakage or short-circuit)
Output DC voltage (
) (for RS2)
Output DC voltage (
+) (for RS1)
VCC/2 (normal DC voltage)
Capacitor leakage
or short-circuit
Vbias
Vref/2
A
B
R
S2
RS1
