參數資料
| 型號： | SFH6319 |
| 廠商： | SIEMENS A G |
| 元件分類： | 光電耦合器 |
| 英文描述： | LOW CURRENT, HIGH GAIN OPTOCOUPLER |
| 中文描述： | 1 CHANNEL LOGIC OUTPUT OPTOCOUPLER |
| 封裝： | SOIC-8 |
| 文件頁數： | 1/3頁 |
| 文件大?。?/td> | 48K |
| 代理商： | SFH6319 |
1
Maximum Ratings (25
Emitter
Reverse Input Voltage....................................................................... 3 V
Supply and Output Voltage, VCC (pin 8-5), VO (pin 6-5)
SFH6318........................................................................... –0.5 to 7 V
SFH6319......................................................................... –0.5 to 18 V
Input Power Dissipation..............................................................35 mW
Derate Linearly above 50
°
C
Free Air Temperature.........................................................0.7 mW/
Average Input Current..................................................................20 mA
Peak Input Current.......................................................................40 mA
(50% Duty Cycle-1 ms pulse width)
Peak Transient Input Current
(tp
≤
1
μ
sec, 300 pps) ..................................................................1.0 A
Detector (Si Photodiode + Photodarlington)
Output Current IO (pin 6).............................................................60 mA
Emitter-Base Reverse Voltage (pin 5-7)......................................... 0.5 V
Output Power Dissipation .........................................................150 mW
Derate Linearly from 25
°
C ...................................................2 mW/
Package
Storage Temperature .................................................. –55
Operating Temperature................................................. –40
Lead Soldering Temperature (t=10 sec.) ..................................... 260
Junction Temperature .................................................................. 100
Ambient Temperature Range...................................... –55
Isolation Test Voltage between
Emitter and Detector...................................................2500 VACRMS
(refer to climate DIN 40046, part 2, Nov. 74)
Pollution Degree (DIN VDE 0110).........................................................2
Creepage Distance......................................................................
Clearance ....................................................................................
Comparative Tracking Index
per DIN IEC 112/VDE 0303, part 1.............................................. 175
Isolation Resistance
VIO=500 V, TA=25
°
C RISOL.................................................
VIO=500 V, TA=100
°
C RISOL...............................................
°
)
°
C
°
C
°
C to +125
°
C to +85
°
°
°
°
°
C
C
C
C
C
°
C to +100
≥
≥
4 mm
4 mm
≥
≥
1012W
1011W
Package Dimensions in Inches (mm)
.120
±
.002
(3.05
±
.05)
TOLERANCE:
±
.005 (unless otherwise noted)
40
°
Lead
Coplanarity
±
.0015 (.04)
max.
.015
±
.002
(.38
±
.05)
.008 (.20)
7
°
.058
±
.005
(1.49
±
.13)
.125
±
.005
(3.18
±
.13)
.050
(1.27)
typ.
.192
±
.005
(4.88
±
.13)
.004 (.10)
.008 (.20)
.021
(.53)
5
°
max.
R.010
(.25)
max.
.020
±
.004
(.15
±
.10)
2 plcs.
.240
(6.10)
.016
(.41)
Pin 1
CL
1
2
3
4
8
7
6
5
.154
±
.002
(.391
±
.05)
V
CC
NC
Anode
Cathode
NC
V
0
V
B
GND
FEATURES
Industry Standard SOIC-8 Surface Mountable
Package
High Current Transfer Ratio, 800%
Low Input Current, 0.5mA
High Output Current, 60mA
Isolation Test Voltage, 2500 VACRMS
TTL Compatible Output, VOL=0.1 V
Adjustable Bandwidth-Access to Base
Underwriters Lab File #E52744
APPLICATIONS
Logic Ground Isolation-TTL/TTL, TTL/CMOS,
CMOS/CMOS, CMOS/TTL
EIA RS 232C Line Receiver
Low Input Current Line Receiver-Long Lines,
Party Lines
Telephone Ring Detector
117 VAC Line Voltage Status Indication-Low
Input Power Dissipation
Low Power Systems-Ground Isolation
DESCRIPTION
Very high current ratio together with 2500 VAC isolation
are achieved by coupling an LED with an integrated high
gain photodetector in a SOIC-8 package. Separate pins
for the photodiode and output stage enable TTL compat-
ible saturation voltages with high speed operation. Pho-
todarlington operation is achieved by tying the VCC and
VO terminals together. Access to the base terminal
allows adjustment to the gain bandwidth.
The SFH6318 is ideal for TTL applications since the
300% minimum current transfer ratio with an LED current
of 1.6 mA enables operation with one unit load-in and
one unit load-out with a 2.2 KW pull-up resistor.
The SFH6319 is best suited for low power logic applica-
tions involving CMOS and low power TTL. A 400% cur-
rent transfer ratio with only 0.5 mA of LED current is
guaranteed from 0
°
C to 70
°
C.
Caution:
Due to the small geometries of this device, it should be handled
with Electrostatic Discharge (ESD) precautions. Proper ground-
ing would prevent damage further and/or degradation which
may be induced by ESD.
SFH6318
SFH6319
LOW CURRENT, HIGH GAIN
OPTOCOUPLER
