SPEC NO: DSAD2331
REV NO: V.4
DATE: NOV/23/2005
PAGE: 2 OF 4
APPROVED: J. Lu
CHECKED: Joe Lee
DRAWN: Y.L.LI
ERP:1301000830
Selection Guide
Electrical / Optical Characteristics at TA=25°C
Absolute Maximum Ratings at TA=25°C
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
Part No.
Dice
Lens Type
Iv (ucd)
@ 10mA
Min.
Typ.
SC23-12GWA
GREEN (GaP)
WHITE DIFFUSED
4700
24000
Common Cathode, Rt.
Hand Decimal.
Description
Parameter
Green
Units
Power dissipation
Per Segment (Dp)
250 (125)
mW
DC Forward Current
Per Segment (Dp)
25
mA
Peak Forward Current [1]
Per Segment (Dp)
140
mA
Reverse Voltage
Per Segment (Dp)
20 (10)
V
Operating / Storage Temperature
-40°C To +85°C
Lead Solder Temperature [2]
260°C For 5 Seconds
Symbol
Parameter
Device
Typ.
Max.
Test Conditions
Units
λpeak
Peak Wavelength
Green
565
nm
IF=20mA
λD
Dominant Wavelength
Green
568
nm
IF=20mA
λ1/2
Spectral Line Half-width
Green
30
nm
IF=20mA
C
Capacitance
Green
15
pF
VF=0V;f=1MHz
VF
Forward Voltage
Per Segment or (Dp)
Green
8.6
(4.4)
10
(5)
V
IF=20mA
IR
Reverse Current
Per Segment or (Dp)
Green
10
uA
VR = 20V
(VR = 10V)
