參數資料
型號： SAF-XC164TM-4F40F
廠商： INFINEON TECHNOLOGIES AG
元件分類： 微控制器/微處理器
英文描述： 16-BIT, FLASH, 40 MHz, MICROCONTROLLER, PQFP64
封裝： 0.50 MM PITCH, GREEN, PLASTIC, TQFP-64
文件頁數： 56/66頁
文件大?。?/td> 1936K
代理商： SAF-XC164TM-4F40F
XC164TM
16-Bit Single-Chip Microcontroller with C166SV2 Core
XC166 Family
Data Sheet
4
V1.2, 2007-03
1
Summary of Features
For a quick overview or reference, the XC164TM’s properties are listed here in a
condensed way.
High Performance 16-bit CPU with 5-Stage Pipeline
– 25 ns Instruction Cycle Time at 40 MHz CPU Clock (Single-Cycle Execution)
– 1-Cycle Multiplication (16
× 16 bit), Background Division (32 / 16 bit) in 21 Cycles
– 1-Cycle Multiply-and-Accumulate (MAC) Instructions
– Enhanced Boolean Bit Manipulation Facilities
– Zero-Cycle Jump Execution
– Additional Instructions to Support HLL and Operating Systems
– Register-Based Design with Multiple Variable Register Banks
– Fast Context Switching Support with Two Additional Local Register Banks
– 16 Mbytes Total Linear Address Space for Code and Data
– 1024 Bytes On-Chip Special Function Register Area (C166 Family Compatible)
16-Priority-Level Interrupt System with up to 63 Sources, Sample-Rate down to 50 ns
8-Channel Interrupt-Driven Single-Cycle Data Transfer Facilities via
Peripheral Event Controller (PEC), 24-Bit Pointers Cover Total Address Space
Clock Generation via on-chip PLL (factors 1:0.15 … 1:10), or
via Prescaler (factors 1:1 … 60:1)
On-Chip Memory Modules
– 2 Kbytes On-Chip Dual-Port RAM (DPRAM)
– 0/2/4 Kbytes1) On-Chip Data SRAM (DSRAM)
– 2 Kbytes On-Chip Program/Data SRAM (PSRAM)
– 32/64/1281) Kbytes On-Chip Program Memory (Flash Memory)
On-Chip Peripheral Modules
– 14-Channel A/D Converter with Programmable Resolution (10-bit or 8-bit) and
Conversion Time (down to 2.55
μs or 2.15 μs)
– 16-Channel General Purpose Capture/Compare Unit (CAPCOM2)
– Multi-Functional General Purpose Timer Unit with 5 Timers
– Two Synchronous/Asynchronous Serial Channels (USARTs)
– Two High-Speed-Synchronous Serial Channels
– On-Chip Real Time Clock, Driven by the Main Oscillator
Idle, Sleep, and Power Down Modes with Flexible Power Management
Programmable Watchdog Timer and Oscillator Watchdog
1) Depends on the respective derivative. See Table 1 “XC164TM Derivative Synopsis” on Page 6.
相關PDF資料
PDF描述
SAF-XC164TM-8F20F 16-BIT, FLASH, 40 MHz, MICROCONTROLLER, PQFP64
SAF-XC2220U-8F66V 32-BIT, FLASH, 66 MHz, RISC MICROCONTROLLER, PQCC48
SAH-XC2220U-4F66V 32-BIT, FLASH, 66 MHz, RISC MICROCONTROLLER, PQCC48
SAF-XC2224L-12F66V 32-BIT, FLASH, 66 MHz, RISC MICROCONTROLLER, PQCC48
SAF-XC2224L-20F66V 32-BIT, FLASH, 66 MHz, RISC MICROCONTROLLER, PQCC48
相關代理商/技術參數
參數描述
SAF-XC164TM-4F40F AA 功能描述:16位微控制器 - MCU 16-Bit Single-Chip 5V 40MHz Flash RoHS:否 制造商:Texas Instruments 核心:RISC 處理器系列:MSP430FR572x 數據總線寬度:16 bit 最大時鐘頻率:24 MHz 程序存儲器大小:8 KB 數據 RAM 大小:1 KB 片上 ADC:Yes 工作電源電壓:2 V to 3.6 V 工作溫度范圍:- 40 C to + 85 C 封裝 / 箱體:VQFN-40 安裝風格:SMD/SMT
SAFXC164TM4F40FAAXT 制造商:Infineon Technologies AG 功能描述:MCU 16-Bit XC166 CISC/DSP/RISC 32KB Flash 2.5V/5V 64-Pin TQFP
SAF-XC164TM-8F20F 制造商:Infineon Technologies AG 功能描述:16BIT MCU 64K FLASH SMD 164TM-8
SAF-XC164TM-8F20F AA 功能描述:16位微控制器 - MCU 16-Bit Single-Chip 5V 20MHz Flash RoHS:否 制造商:Texas Instruments 核心:RISC 處理器系列:MSP430FR572x 數據總線寬度:16 bit 最大時鐘頻率:24 MHz 程序存儲器大小:8 KB 數據 RAM 大小:1 KB 片上 ADC:Yes 工作電源電壓:2 V to 3.6 V 工作溫度范圍:- 40 C to + 85 C 封裝 / 箱體:VQFN-40 安裝風格:SMD/SMT
SAFXC164TM8F20FAAXT 制造商:Infineon Technologies AG 功能描述:MCU 16-Bit XC166 CISC/DSP/RISC 64KB Flash 2.5V/5V 64-Pin TQFP
