XC164LM
Derivatives
Electrical Parameters
Data Sheet
54
V1.2, 2007-03
4.3.2
On-chip Flash Operation
The XC164LM’s Flash module delivers data within a fixed access time (see Table 15).
Accesses to the Flash module are controlled by the PMI and take 1+WS clock cycles,
where WS is the number of Flash access waitstates selected via bitfield WSFLASH in
register IMBCTRL. The resulting duration of the access phase must cover the access
time
t
ACC of the Flash array. The required Flash waitstates depend on the actual system
frequency.
The Flash access waitstates only affect non-sequential accesses. Due to prefetching
mechanisms, the performance for sequential accesses (depending on the software
structure) is only partially influenced by waitstates.
In typical applications, eliminating one waitstate increases the average performance by
5% … 15%.
Example: For an operating frequency of 40 MHz (clock cycle = 25 ns), the Flash
accesses must be executed with 1 waitstate: ((1+1)
× 25 ns) ≥ 50 ns.
Table 16 indicates the interrelation of waitstates and system frequency.
Note: The maximum achievable system frequency is limited by the properties of the
respective derivative, i.e. 40 MHz (or 20 MHz for XC164LM-xF20F devices).
Table 15
Flash Characteristics (Operating Conditions apply)
Parameter
Symbol
Limit Values
Unit
Min.
Typ.
Max.
Flash module access time
t
ACC
CC ––501)
1) The actual access time is influenced by the system frequency, see Table 16.
ns
Programming time per 128-byte block
t
PR
CC –
22)
2) Programming and erase time depends on the system frequency. Typical values are valid for 40 MHz.
5ms
Erase time per sector
t
ER
CC –
2002)
500
ms
Table 16
Flash Access Waitstates
Required Waitstates
Frequency Range
0 WS (WSFLASH = 00B)
f
CPU ≤ 20 MHz
1 WS (WSFLASH = 01B)
f
CPU ≤ 40 MHz
