RT9002A/B/C
8
DS9002ABC-03 March 2007
www.richtek.com
Load Transient Response
Time (500
μ
s/Div)
I
OUT1
(100mA/Div)
V
OUT1
(5mV/Div)
V
OUT2
(50mV/Div)
RT9002A
I
LOAD
= 10mA to 100mA
Line Transient Response
Time (250
μ
s/Div)
V
OUT
(1V/Div)
5
4
V
OUT1
(20mV/Div)
V
OUT2
(20mV/Div)
RT9002A
Boost I
LOAD
= 50mA
RT9002A, V
OUT1
I
LOAD
= 75mA
EN Pin Shutdown Response
Time (100
μ
s/Div)
S
(
V
O
(
Start Up
Time (10
μ
s/Div)
S
(
V
O
(
RT9002A, V
OUT1
I
LOAD
= 75mA
Dropout Voltage vs. Load Current
0
100
200
300
400
500
600
0
0.1
0.2
0.3
0.4
0.5
Load Current (A)
D
RT9002C, V
OUT2
= 3.3V
-40
°
C
25
°
C
125
°
C
Dropout Voltage vs. Load Current
0
50
100
150
200
250
300
350
400
0
50
100
Load Current (mA)
150
200
250
300
D
RT9002A, V
OUT1
= 2.5V
-40
°
C
25
°
C
125
°
C
