Picor Corporation picorpower.com
QPI-6
Rev 2.6, Page 7 of 13
QPI-6
QUIETPOWER
QPI Application Circuits:
Filtering Dual Converters
Figure 13 – The QPI-6 filtering dual supplies, using a single RY resistor.
(4)
The shield plane under the two converters in Figure 13 should
be one contiguous plane under both. The circuit in Figure 13 is
capable of filtering more converters than shown, up to the
maximum current limit of the QPI-6. In Figure 14, a separate
shield plane is required for each converter along with a
separate RY resistor.
The QPI-6 is not designed to be used in parallel with another
QPI-6 to achieve a higher current rating, but it can be used
multiple times within a system design.
Filtering Parallel Converters
Figure 14 – Dual QPI-6’s filtering paralleled converters feeding a common load.
(4)
Note 4: In Figures 12 and 13; CIN1 and CIN2, CY1 through CY8, should be the value and voltage rating recommended by the converter’s manufacturer.
