| 型號： | PI6C557-05LE |
| 廠商： | Pericom |
| 文件頁數： | 2/9頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC CLOCK GENERATOR 20-TSSOP |
| 產品培訓模塊： | Total Timing Technology |
| 標準包裝： | 74 |
| 系列： | PCI Express® (PCIe) |
| 類型： | 時鐘/頻率發生器 |
| PLL： | 是 |
| 主要目的： | 以太網，PCI Express（PCIe） |
| 輸入： | 時鐘，晶體 |
| 輸出： | HCSL，LVDS |
| 電路數： | 1 |
| 比率 - 輸入:輸出： | 1:4 |
| 差分 - 輸入:輸出： | 無/是 |
| 頻率 - 最大： | 200MHz |
| 電源電壓： | 3.135 V ~ 3.465 V |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 20-TSSOP（0.173"，4.40mm 寬） |
| 供應商設備封裝： | 20-TSSOP |
| 包裝： | 管件 |
2
PI6C557-05
PCIe 2.0 Clock Generator with 4 HCSL Outputs
www.pericom.com
P-0.1
04/29/11
All trademarks are property of their respective owners.
Pin Description
Pin #
Pin Name
I/O Type Description
1
VDDXD
Power
Connect to a +3.3V source.
2
S0
Input
Spread Spectrum Select pin #0. See Spread Spectrum Selection table. Internal pull-up resistor.
3
S1
Input
Spread Spectrum Select pin #1. See Spread Spectrum Selection table. Internal pull-up resistor.
4
S2
Input
Spread Spectrum Select pin #2. See Spread Spectrum Selection table. Internal pull-up resistor.
5
X1
Input
Crystal connection.
6
X2
Output
Crystal connection.
7
PD
Input
Power down. Internal pull-up resistor.
8
OE
Input
Output enable. Tri-states output (High=enable outputs); Low=disable outputs). Internal pull-
up resistor.
9
GND
Power
Connect to digital circuit ground.
10
IREF
Output
Precision resistor attached to this pin is connected to the internal current reference.
11
CLK3
Output
Selectable 100/200 MHz Spread Spectrum differential compliment output clock 3.
12
CLK3
Output
Selectable 100/200 MHz Spread Spectrum differential true output clock 3.
13
CLK2
Output
Selectable 100/200 MHz Spread Spectrum differential compliment output clock 2.
14
CLK2
Output
Selectable 100/200 MHz Spread Spectrum differential true output clock 2.
15
VDDODA
Power
Connect to a +3.3V analog source.
16
GND
Power
Output and Analog circuit ground
17
CLK1
Output
Selectable 100/200 MHz Spread Spectrum differential compliment output clock 1.
18
CLK1
Output
Selectable 100/200 MHz Spread Spectrum differential true output clock 1.
19
CLK0
Output
Selectable 100/200 MHz Spread Spectrum differential compliment output clock 0.
20
CLK0
Output
Selectable 100/200 MHz Spread Spectrum differential true output clock 0.
Table 2: Spread Selection Table
S2
S1
S0
Spread %
Spread Type
Output Frequency
0
-0.5
Down
100
0
1
-1.0
Down
100
0
1
0
-1.5
Down
100
0
1
No Spread
Not Applicable
100
1
0
-0.5
Down
200
1
0
1
-1.0
Down
200
1
0
-1.5
Down
200
1
No Spread
Not Applicable
200
11-0063
