參數資料
| 型號： | PI4ULS5V104GAEX |
| 廠商： | Pericom |
| 文件頁數： | 5/12頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC LOGIC TRANSLATOR |
| 標準包裝： | 1 |
| 系列： | ULS |
| 邏輯功能： | 電平移位器，雙向，3 態 |
| 位數： | 4 |
| 輸入類型： | 電壓 |
| 輸出類型： | 電壓 |
| 數據速率： | 100Mbps |
| 通道數： | 4 |
| 輸出/通道數目： | 1 |
| 差分 - 輸入:輸出： | 無/無 |
| 傳輸延遲（最大）： | 4ns |
| 電源電壓： | 1.2 V ~ 3.6 V，1.65 V ~ 5.5 V |
| 工作溫度： | -40°C ~ 85°C |
| 封裝/外殼： | 12-UFBGA，CSPBGA |
| 供應商設備封裝： | 12-CSP（1.87x1.37） |
| 包裝： | 標準包裝 |
| 其它名稱： | PI4ULS5V104GAEXDKR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
12-07-0010
PT0335-4
08/24/12
2
PI4ULS5V104
4-Bit Bi-directional Level Shifter with
Automatic Direction Controller
Pin Description
Pin Name
Description
VCCA
A-port supply voltage 1.2 V ≤ VCCA ≤ 3.6 V and VCCA ≤ VCCB.
A1
Input/output 1. Referenced to VCCA.
A2
Input/output 2. Referenced to VCCA.
A3
Input/output 3. Referenced to VCCA.
A4
Input/output 4. Referenced to VCCA.
GND
Ground
OE
3-State output. Pull OE low to place all outputs in 3-state mode. Referenced to VCCA.
B4
Input/output 4. Referenced to VCCB.
B3
Input/output 3. Referenced to VCCB.
B2
Input/output 2. Referenced to VCCB.
B1
Input/output 1. Referenced to VCCB.
VCCB
B-port supply voltage 1.65 V ≤ VCCB ≤ 5.5 V.
Maximum Ratings
*1
Min
Max
Unit
VCCA
Supply voltage range
-0.5
4.6
V
VCCB
-0.5
6.5
VI
Input voltage range
A port
-0.5
4.6
V
B port
-0.5
6.5
VO
Voltage range applied to any output in the high-impedance or
power-off state
A port
-0.5
4.6
V
B port
-0.5
6.5
VO
Voltage range applied to any output in the high or low state
*2
A port
-0.5
VCCA + 0.5
V
B port
-0.5
VCCB + 0.5
IIK
Input clamp current, VI < 0
-
-50
mA
IOK
Output clamp current, VO < 0
-
-50
mA
IO
Continuous output current
-
±50
mA
IO
Continuous current through VCCA, VCCB, or GND
-
±100
mA
Tstg
Storage temperature range
-65
150
℃
*1 Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and
functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not
implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.
*2 The value of VCCA and VCCB are provided in the recommended operating conditions table.
