| 型號： | PI3L500ZFE |
| 廠商： | Pericom |
| 文件頁數： | 1/7頁 |
| 文件大小： | 0K |
| 描述： | IC ETHERNET SWITCH OCTAL 56TQFN |
| 標準包裝： | 33 |
| 功能： | 以太網開關 |
| 電路： | 8 x 2:1 |
| 導通狀態電阻： | 6.5 歐姆 |
| 電壓電源： | 單電源 |
| 電壓 - 電源，單路/雙路(±)： | 3 V ~ 3.6 V |
| 電流 - 電源： | 500nA |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 56-WFQFN 裸露焊盤 |
| 供應商設備封裝： | 56-TQFN-EP（5x11） |
| 包裝： | 托盤 |
| 產品目錄頁面： | 1225 (CN2011-ZH PDF) |
1
PS8719D
03/23/07
Features
RON is 4Ω (typical)
Low bit-to-bit skew: 200ps
Low Crosstalk: –22dB @ 250 MHz
Near-Zero propagation delay: 250ps
Switching speed: 9ns
Channel On capacitance: 10pF (typical)
Live Insertion Capable
Status Indicator LEDs Switched with Ethernet pairs
VCC Operating Range: +3.0V to +3.6V
>3kV ESD protection (human body model)
>350 MHz bandwidth (or data frequency)
Packaging (Pb-free and Green available):
– 56-contact TQFN (ZF)
Applications
Dual Physical Layer Device sharing to one interface
connector
Routes signals for 10/100/1000 Mbit Ethernet
Description
The PI3L500 is a 16- to 8- Channel multiplexer/demultiplexer LAN
Switch with Hi-Z outputs. Industry leading advantages include a
propagation delay of less than 250ps, resulting from its low channel
resistance and I/O capacitance.
The device multiplexes differential outputs from a Gigabit Ethernet
transceiver (PHY) device to one of two corresponding B1 or B2
outputs.The switch is bidirectional and offers little or no attenuation
of the high-speed signals at the outputs. It is designed for low bit-to-
bit skew, high channel-to-channel noise isolation and is compatible
with various standards, such as 10/100/1000 Base-T (Ethernet).
Generally, this part can be used to replace mechanical relays in
low-voltage LAN applications that interface a physical layer over
CAT 5 or CAT 6 unshielded twisted pair cable through an isolation
transformer.
Block Diagram
Pin Description
PI3L500
3.3V, 8-Channel, 2:1 Mux/DeMux
Gigabit Ethernet LAN Switch with Single Enable
GND
A0
A1
VCC
N.C.
GND
A2
A3
GND
VCC
A4
A5
GND
A6
A7
GND
SEL
VCC
LED0
LED1
0B1
1B1
0B2
1B2
GND
2B1
3B1
2B2
3B2
GND
VCC
4B1
5B1
4B2
5B2
GND
6B1
7B1
6B2
7B2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
V
CC
GND
LED
2
GND
2
LED
1
2
LED
2
V
CC
GND
0
LED
1
LED
1
GND
0
LED
2
1
LED
2
V
CC
GND
21
22
23
24
25
26
27
28
56
55
54
53
52
51
50
49
SEL
A7
A6
A1
A0
1B1
0B1
1B2
0B2
7B1
6B1
7B2
6B2
LEDz
zLED1
zLED2
07-0075
