參數資料
| 型號： | P89LPC9401FBD,551 |
| 廠商： | NXP Semiconductors |
| 文件頁數： | 13/59頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC 80C51 MCU FLASH 8K 64-LQFP |
| 標準包裝： | 90 |
| 系列： | LPC900 |
| 核心處理器： | 8051 |
| 芯體尺寸： | 8-位 |
| 速度： | 18MHz |
| 連通性： | I²C，SPI，UART/USART |
| 外圍設備： | 欠壓檢測/復位，LCD，LED，POR，PWM，WDT |
| 輸入/輸出數： | 23 |
| 程序存儲器容量： | 8KB（8K x 8） |
| 程序存儲器類型： | 閃存 |
| RAM 容量： | 256 x 8 |
| 電壓 - 電源 (Vcc/Vdd)： | 2.4 V ~ 3.6 V |
| 振蕩器型： | 內部 |
| 工作溫度： | -40°C ~ 85°C |
| 封裝/外殼： | 64-LQFP |
| 包裝： | 托盤 |
| 配用： | 568-4000-ND - DEMO BOARD SPI/I2C TO DUAL UART 568-3510-ND - DEMO BOARD SPI/I2C TO UART 568-1759-ND - EMULATOR DEBUGGER/PROGRMMR LPC9X |
| 其它名稱： | 568-3227 935278626551 P89LPC9401FBD-S |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁當前第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁第36頁第37頁第38頁第39頁第40頁第41頁第42頁第43頁第44頁第45頁第46頁第47頁第48頁第49頁第50頁第51頁第52頁第53頁第54頁第55頁第56頁第57頁第58頁第59頁
P89LPC9401_1
Koninklijke Philips Electronics N.V. 2005. All rights reserved.
Preliminary data sheet
Rev. 01 — 5 September 2005
20 of 59
Philips Semiconductors
P89LPC9401
8-bit two-clock 80C51 microcontroller with 32 segment
× 4 LCD driver
CODE
64 kB of Code memory space, accessed as part of program execution and via the
MOVC instruction. The P89LPC9401 has 8 kB of on-chip Code memory.
7.11 Data RAM arrangement
The 768 bytes of on-chip RAM are organized as shown in Table 5.
7.12 Interrupts
The P89LPC9401 uses a four priority level interrupt structure. This allows great exibility
in controlling the handling of the many interrupt sources. The P89LPC9401 supports
13 interrupt sources: external interrupts 0 and 1, timers 0 and 1, serial port TX, serial port
RX, combined serial port RX/TX, brownout detect, watchdog/RTC, I2C-bus, keyboard,
comparators 1 and 2, and SPI.
Each interrupt source can be individually enabled or disabled by setting or clearing a bit in
the interrupt enable registers IEN0 or IEN1. The IEN0 register also contains a global
disable bit, EA, which disables all interrupts.
Each interrupt source can be individually programmed to one of four priority levels by
setting or clearing bits in the interrupt priority registers IP0, IP0H, IP1, and IP1H. An
interrupt service routine in progress can be interrupted by a higher priority interrupt, but
not by another interrupt of the same or lower priority. The highest priority interrupt service
cannot be interrupted by any other interrupt source. If two requests of different priority
levels are pending at the start of an instruction, the request of higher priority level is
serviced.
If requests of the same priority level are pending at the start of an instruction, an internal
polling sequence determines which request is serviced. This is called the arbitration
ranking. Note that the arbitration ranking is only used to resolve pending requests of the
same priority level.
7.12.1 External interrupt inputs
The P89LPC9401 has two external interrupt inputs as well as the Keypad Interrupt
function. The two interrupt inputs are identical to those present on the standard 80C51
microcontrollers.
These external interrupts can be programmed to be level-triggered or edge-triggered by
setting or clearing bit IT1 or IT0 in Register TCON.
In edge-triggered mode, if successive samples of the INTn pin show a HIGH in one cycle
and a LOW in the next cycle, the interrupt request ag IEn in TCON is set, causing an
interrupt request.
If an external interrupt is enabled when the P89LPC9401 is put into Power-down or Idle
mode, the interrupt will cause the processor to wake-up and resume operation. Refer to
Section 7.15 “Power reduction modes” for details.
Table 5:
On-chip data memory usages
Type
Data RAM
Size (bytes)
DATA
Memory that can be addressed directly and indirectly
128
IDATA
Memory that can be addressed indirectly
256
