OSC Series Ultra Miniature TCXO s
Vectron International 166 Glover Avenue, Norwalk, CT 06856 Tel: 1-88-VECTRON-1 Fax: 1-888-FAX-VECTRON
Terminal #1
identifier
0.025 (0.7)
4 places
0.050 (1.3)
4 places
0.040 (1.2)
4 places
0.300
(7.62)
0.020
(0.5)
0.09
(2.2)
max
0.055 (1.4)
2 places
Frequency
adjust
access
0.47
(11.8)
max
0.39
(9.9)
max
1
2
3
4
1
2
3
4
1.9mm
8.4mm
7
1.9mm
1
1
Model OSC
Land Pattern
Convection Reflow Profile
warm-up
>30 sec.
pre-heating
50 to 90 sec at
reflow
20 to 40 soc
The OSC series of TCXO s and VCTCXO s has
been designed for pick and place and reflow sol-
dering. Units are available on
Tape and Reel
at
no additional charge when ordering a complete
reel. The reel size is 2000 pcs and is compatible
with EIAJ-1009B standards. The suggested
reflow profile is shown below. The TCXO may be
reflowed two times. Frequency shift as a result of
reflow will be <1.0PPM. Units should not be
adjusted to center frequencies until at least 2
hours after reflow to allow the crystals to stabilize.
The OSC footprint is compatible with many of the
previous generation 6 pin leaded TCXO s. Our
OSE
model is the same size as the OSC except it
provides the two additional pads to match pad con-
nections of 6 pin leaded TCXO s and VCTCXO s.
TCXO s are precision subsystems with tolerances
measured to
cally sealed TCXO s should not be subjected to a
wash process that will immerse the TCXO in sol-
vents.
No clean
is the recommended procedure.
Non-hermeti-
PIN 1 = VC or N/C
PIN 2 = GROUND
PIN 3 = OUTPUT
PIN 4 = B+
3
