- 您現在的位置：買賣IC網 > PDF目錄98044 > MSM65516-XXXGS-BK (OKI ELECTRIC INDUSTRY CO LTD) 8-BIT, MROM, 10 MHz, MICROCONTROLLER, PQFP64 PDF資料下載
參數資料
| 型號： | MSM65516-XXXGS-BK |
| 廠商： | OKI ELECTRIC INDUSTRY CO LTD |
| 元件分類： | 微控制器/微處理器 |
| 英文描述： | 8-BIT, MROM, 10 MHz, MICROCONTROLLER, PQFP64 |
| 封裝： | 14 X 14 MM, 0.80 MM PITCH, PLASTIC, QFP-64 |
| 文件頁數： | 5/23頁 |
| 文件大?。?/td> | 198K |
| 代理商： | MSM65516-XXXGS-BK |
13/23
Semiconductor
MSM65516/65P516
DC Characteristics 2 (2.7
VDD < 4.5V)
(GND=0V, Ta=–40 to +85°C)
Parameter
Symbol
Condition
Min.
Typ.
Max.
Unit
"H" Input Voltage 1 *1
VIH1
—
0.5VDD+0.2
—
VDD+0.3
"H" Input Voltage 2 *2
VIH2
—
0.6VDD+0.4
—
VDD+0.3
"L" Input Voltage
VIL
—
–0.3
—
0.15VDD+0.1
"H" Output Voltage 1 *3
VOH1
IOH=–10mA
0.75VDD
——
"H" Output Voltage 2 *4
VOH2
IOH=–20mA
0.75VDD
——
"L" Output Voltage 1 *3
VOL1
IOL=10mA
—
0.1
"L" Output Voltage 2 *4
VOL2
IOL=20mA
—
0.1
Input Lack Current 1 *5
ILI1
VI=VDD/0V
—
±1
Input Lack Current 2 *6
ILI2
VI=VDD/0V
—
±10
"L" Input Current *7
IIL
VDD=2.7 to 3.3V, VI=0V
–40
–120
–240
Input Capacity
CI
f=1MHz, Ta=25°C
—
5
—
Still Current Consumption
IDDS
3V, Stop mode *8
——
25
Operating Current Consumption
IDD
5MHz, 3V, no load
Refer to Fig.2
—6
15
V
mA
pF
mA
*1 Excluding OSC0 and RESET
*2 OSC0 and RESET
*3 Excluding P0, ALE, RD, P2.6/WR
*4 P0, ALE, RD, P2.6/WR
*5 EA, P6
*6 Excluding RESET, EA, P6
*7 RESET
*8 The ports configured as inputs should be coupled to VDD or 0V. Other ports should not be
loaded.
