MS376RAA Series (1206)
1102 Silver Lake Road
Cary IL 60013
Phone
Fax
800-981-0363
847-639-1508
E-mail
Web
cps@coilcraft.com
www.coilcraft-cps.com
Coilcraft, Inc. 2011
Specifications subject to change without notice.
Please check our website for latest information.
1206 CHIP INDUCTORS
Document MS104-2
Revised 02/28/11
Typical Q vs Frequency
Typical L vs Frequency
1000
10000
100
10
1
100
10
Frequency (MHz)
Inductance
(nH)
1000
1
1200 nH
560 nH
150 nH
47 nH
18 nH
3.3 nH
0
10
20
30
40
50
60
70
80
90
100
110
120
10
100
1000
10000
Frequency (MHz)
Q
F
actor
15 nH
3.3 nH
33 nH
150 nH
680 nH
330 nH
Current Derating
A max B max C max
D ref
E
F
G
H
I
J
0.140
0.085
0.060
0.020
0.056
0.020 0.080
0.076 0.040 0.070
3,56
2,16
1,52
0,51
1,42
0,51
2,03
1,93
1,02
1,78
Core material Ceramic
Terminations Tin-lead (63/37) over silver-platinum-glass frit
Ambient temperature –55°C to +125°C with
Imax current, +125°C
to +155°C with derated current
Storage temperature Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL) +25 to +155 ppm/°C
Moisture Sensitivity Level (MSL) 1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging 2000 per 7
″ reel
Plastic tape: 8 mm wide, 0.3 mm thick, 4 mm pocket spacing,
1.6 mm pocket depth
-40
-20
0
20
40
60
80
100
160
140
120
Ambient temperature (°C)
P
e
rcent
of
rated
rmsI
120
110
100
90
80
70
60
50
40
30
20
10
0
25°C
A
B
overall
C
D
Terminal wraparound:
approx 0.015/0,38 both ends
I
J
F
G
H
E
terminal
Suggested
Land Pattern
Note: Dimensions are before solder application. For maximum overall
dimensions including solder, add 0.0025 in / 0,064 mm to B and
0.006 in / 0,15 mm to A and C.
