參數資料
| 型號： | MM3Z2V7ST3 |
| 廠商： | ON SEMICONDUCTOR |
| 元件分類： | 參考電壓二極管 |
| 英文描述： | 128 x 128 pixel format, LED Backlight available |
| 中文描述： | 2.7 V, 0.2 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE |
| 封裝： | 0.067 X 0.049 INCH, 0.035 INCH HEIGHT, PLASTIC, CASE 477-02, 2 PIN |
| 文件頁數： | 4/4頁 |
| 文件大?。?/td> | 45K |
| 代理商： | MM3Z2V7ST3 |
MM3Z2V4ST1 SERIES
http://onsemi.com
4
PACKAGE DIMENSIONS
NOTES:
1. DIMENSIONING AND TOLERANCING PER
ANSI Y14.5M, 1982.
2. CONTROLLING DIMENSION: MILLIMETERS.
3. LEAD THICKNESS SPECIFIED PER L/F
DRAWING WITH SOLDER PLATING.
4. DIMENSIONS A AND B DO NOT INCLUDE
MOLD FLASH, PROTRUSIONS OR GATE
BURRS.
5. DIMENSION L IS MEASURED FROM END OF
RADIUS.
DIM
A
B
C
D
E
H
J
K
L
MIN
1.60
1.15
0.80
0.25
0.15 REF
0.00
0.089
2.30
0.075
MAX
1.80
1.35
1.00
0.40
MIN
0.063
0.045
0.031
0.010
0.006 REF
0.000
0.0035
0.091
0.003
MAX
0.071
0.053
0.039
0.016
INCHES
MILLIMETERS
0.10
0.177
2.70
0.004
0.0070
0.106
NOTE 3
A
K
1
2
D
B
E
H
C
J
NOTE 5
L
SOD323
CASE 47702
ISSUE E
1.60
0.063
2.85
0.112
0.63
0.025
mm
inches
SCALE 10:1
0.83
0.033
*For additional information on our PbFree strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
SOLDERING FOOTPRINT*
STYLE 1:
PIN 1. CATHODE
2. ANODE
ON Semiconductor
and are registered trademarks of Semiconductor Components Industries, LLC (SCILLC). SCILLC reserves the right to make changes without further notice
to any products herein. SCILLC makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does SCILLC assume any liability
arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages.
“Typical” parameters which may be provided in SCILLC data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All
operating parameters, including “Typicals” must be validated for each customer application by customer’s technical experts. SCILLC does not convey any license under its patent rights
nor the rights of others. SCILLC products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other applications
intended to support or sustain life, or for any other application in which the failure of the SCILLC product could create a situation where personal injury or death may occur. Should
Buyer purchase or use SCILLC products for any such unintended or unauthorized application, Buyer shall indemnify and hold SCILLC and its officers, employees, subsidiaries, affiliates,
and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death
associated with such unintended or unauthorized use, even if such claim alleges that SCILLC was negligent regarding the design or manufacture of the part. SCILLC is an Equal
Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright laws and is not for resale in any manner.
PUBLICATION ORDERING INFORMATION
N. American Technical Support
: 8002829855 Toll Free
USA/Canada
Japan
: ON Semiconductor, Japan Customer Focus Center
291 Kamimeguro, Meguroku, Tokyo, Japan 1530051
Phone
: 81357733850
MM3Z2V4ST1/D
LITERATURE FULFILLMENT
:
Literature Distribution Center for ON Semiconductor
P.O. Box 61312, Phoenix, Arizona 850821312 USA
Phone
: 4808297710 or 8003443860 Toll Free USA/Canada
Fax
: 4808297709 or 8003443867
Toll Free USA/Canada
Email
: orderlit@onsemi.com
ON Semiconductor Website
: http://onsemi.com
Order Literature
: http://www.onsemi.com/litorder
For additional information, please contact your
local Sales Representative.
