MITSUMI
Analog voltage output temperature sensor MM1522XU/XN
Analog voltage output temperature sensor
Monolithic IC MM1522XU/XN
Outline
This is a temperature sensor IC that can obtain +10mV/C linear output voltage relative to temperature
change.
Features
1. Temperature sensitivity
2. Output voltage precision
3. Consumption current
4. Operating power voltage range
5. Operating temperature range
±10mV/C
+3C max.
70μA typ.
+2.7~+10.0V
-
40~+125C
Package
SC-82ABB (MM1522XU)
SOT-25A (MM1522XN)
Applications
1. CPU heat protection
2. Battery charger heat protection
3. Cellular phones
Pin Description
Absolute Maximum Ratings
(Ta=25C)
Item
Symbol
T
STG
T
OPR
V
CC
max.
Rating
-
55~+150
-
40~+125
+13
154 (SC-82ABB)
188 (SOT-25A)
Unit
C
C
V
Storage temperature
Operating temperature
Supply voltage
Allowable loss
Pd
mW
Pin No.
Pin Name
N.C
GND
V
CC
V
OUT
Function
1
2
GND PIN
V
CC
PIN
Output PIN
3
4
Pin No.
Pin Name
N.C
GND
V
CC
V
OUT
Function
1,3
2
GND PIN
V
CC
PIN
Output PIN
4
5
SC-82ABB
SOT-25A
