B137
Note 1: Includes temperature rise caused by current flow.
Note 2: The term "storage" refers to products stored for long period of time prior to mounting and use. Operating Temperature Range and
Humidity range covers non conducting condition of installed connectors in storage, shipment or during transportation.
Note: Hirose's tin plating process takes measures against whisker.
sMaterial
Product
Part
Material
Finish
Remarks
Pin Header
Insulator
Polyamide
Beige
UL94V-0
Contact
Brass
Tin plated
________
sOrdering Information
MDF14A
- * P - 2.5 DS
qe
wr
t
r Contact pitch: 2.5mm
t Connection Type
DS : Right Angle
q Series Name
: MDF 14A
w Number of contacts: 4 to 10
e Connector Type
P : Pin Header
qConnector
sProduct Specifications
Current rating : 5A
Operating Temperature Range: -30 to +85 (Note 1) Storage Temperature Range: -10 to +60 (Note 2)
Voltage rating : 250V AC Operating Moisture Range: 40 to 80%
Storage Moisture Range: 40 to 70%
(Note 2)
Rating
Item
Specification
Condition
1. Insulation Resistance
1000M ohms min.
500V DC
2. Withstanding voltage
No flashover or insulation breakdown.
1500V AC/1 minute
3. Vibration
No damage, cracks, or parts looseness.
Frequency: 10 to 55 Hz, single amplitude of 0.75 mm, 2 hours in each of the 3 directions.
4. Humidity (Steady state) Insulation resistance: 1000M ohms min.
96 hours at temperature of 40 and humidity of 90% to 95%
5. Temperature Cycle
No damage, cracks, or parts looseness.
(-55: 30 minutes5 to 35: 10 minutes max.
(-85: 30 minutes5 to 35: 10 minutes max.) 5 cycles
6. Resistance to Soldering heat
No deformation of components affecting performance.
Flow: 250 for 10 seconds
Manual soldering: 300 for 3 seconds
The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.
All non-RoHS products have been discontinued, or will be discontinued soon. Please check the products status on the Hirose website RoHS search at www.hirose-connectors.com, or contact your Hirose sales representative.
