MBRS1100T3, MBRS190T3
http://onsemi.com
4
PACKAGE DIMENSIONS
SMB
PLASTIC PACKAGE
CASE 403A03
ISSUE F
E
b
D
c
L1
L
A
A1
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982.
2. CONTROLLING DIMENSION: INCH.
3. D DIMENSION SHALL BE MEASURED WITHIN DIMENSION P.
DIM
A
A1
b
c
E
H
E
MIN
1.90
0.05
1.96
0.15
3.30
4.06
5.21
NOM
2.13
0.10
2.03
0.23
3.56
4.32
5.44
MAX
2.45
0.20
2.20
0.31
3.95
4.60
5.60
MIN
0.075
0.002
0.077
0.006
0.130
0.160
0.205
MILLIMETERS
INCHES
NOM
L
L1
0.76
1.02
1.60
0.030
0.084
0.004
0.080
0.009
0.140
0.170
0.214
0.096
0.008
0.087
0.012
0.156
0.181
0.220
0.040
0.020 REF
0.063
MAX
0.51 REF
D
H
E
2.261
0.089
2.743
0.108
2.159
0.085
mm
inches
SCALE 8:1
*For additional information on our PbFree strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
SOLDERING FOOTPRINT*
