Semiconductor Components Industries, LLC, 2005
September, 2005 Rev. 3
1
Publication Order Number:
MBRP30060CT/D
MBRP30060CT
Preferred Device
POWERTAP II
SWITCHMODE
Power Rectifier
These stateoftheart devices use the Schottky Barrier principle
with a platinum barrier metal.
Features
Dual Diode Construction May Be Paralleled for Higher Current
Output
Guardring for Stress Protection
Low Forward Voltage
150
°
C Operating Junction Temperature
PbFree Package is Available*
Mechanical Characteristics:
Case: Epoxy, Molded with Metal Heatsink Base
Weight: 80 Grams (Approximately)
Finish: All External Surfaces Corrosion Resistant
Top Terminal Torque: 2540 lbin Max
Base Plate Torques:
See procedure given in the Package Outline Section
MAXIMUM RATINGS
Rating
Symbol
Max
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
60
V
Average Rectified Forward Current
(Rated V
R
, T
C
= 140
°
C)
Per Leg
Per Device
I
F(AV)
150
300
A
Peak Repetitive Forward Current,
(Rated V
R
, Square Wave,
20 kHz, T
C
= 140
°
C)
Per Leg
I
FRM
300
A
NonRepetitive Peak Surge Current
(Surge Applied at Rated Load Conditions
Halfwave, Single Phase, 60 Hz) Per Leg
I
FSM
2500
A
Peak Repetitive Reverse Current
(2.0 s, 1.0 kHz)
Per Leg
I
RRM
2.0
A
Storage Temperature Range
T
stg
T
J
dv/dt
55 to +150
°
C
°
C
Operating Junction Temperature
55 to +150
Voltage Rate of Change (Rated V
R
)
Maximum ratings are those values beyond which device damage can occur.
Maximum ratings applied to the device are individual stress limit values (not
normal operating conditions) and are not valid simultaneously. If these limits are
exceeded, device functional operation is not implied, damage may occur and
reliability may be affected.
10,000
V/ s
*For additional information on our PbFree strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
SCHOTTKY
BARRIER RECTIFIER
300 AMPERES, 60 VOLTS
1
2
3
Preferred
devices are recommended choices for future use
and best overall value.
http://onsemi.com
Device
Package
Shipping
ORDERING INFORMATION
MBRP30060T
POWERTAP II
25 Units/Tray
POWERTAP II
CASE 357C
PLASTIC
1
2
3
MARKING DIAGRAM
B30060T
B30060T
MCC
A
YY
WW
G
= Specific Device Code
= Mold Compound Code
= Assembly Location
= Year
= Work Week
= PbFree Package
MCC
AYYWWG
MBRP30060TG
POWERTAP II
(PbFree)
25 Units/Tray
