參數資料
型號： MAX5440EAG+
廠商： Maxim Integrated Products
文件頁數： 10/16頁
文件大?。?/td> 0K
描述： IC CNTRL VOL STEREO 24-SSOP
產品培訓模塊： Lead (SnPb) Finish for COTS
Obsolescence Mitigation Program
標準包裝： 58
類型： 立體聲音量控制
應用： 車載系統，臺式音頻，機頂盒
安裝類型： 表面貼裝
封裝/外殼： 24-SSOP（0.209"，5.30mm 寬）
供應商設備封裝： 24-SSOP
包裝： 管件
MAX5440
Stereo Volume Control
with Rotary Encoder Interface
ELECTRICAL CHARACTERISTICS (continued)
(VDD = +2.7V to +5.5V, VSS = VGND = 0, 2.7V ≤ (VDD - VSS) ≤ 5.5V, VLOGIC = +2.7V to VDD, VH_ = VDD, VL_ = VDD / 2, TA = TMIN to
TMAX, unless otherwise specified. Typical values are at TA = +25°C.) (Note 1)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Power-Supply Rejection Ratio
PSRRBR
1kHz, 100mV on VDD, 1F on BIAS
60
dB
Maximum Load
To VDD or GND
3
k
Output Resistance
ROBR
6
CONTACT INPUTS (
MUTE, MODE, RENCODEA, RENCODEB)
Internal Pullup Resistor
RPULLUP
45
k
Single Pulse Input Low Time
tCPW
22
ms
Repetitive Input Pulse Separation
tIPWS
66
ms
Timeout Period
tWS
Click/pop suppression inactive
32
ms
DIGITAL INPUTS (
MUTE, MODE, RENCODEA, RENCODEB, SHDN)
3.6V < VLOGIC
≤ 5.5V
2.4
Input High Voltage (Note 2)
VIH
2.7V
≤ VLOGIC ≤ 3.6V
2.0
V
3.6V < VLOGIC
≤ 5.5V
0.8
Input Low Voltage (Note 2)
VIL
2.7V
≤ VLOGIC ≤ 3.6V
0.6
V
Input Leakage Current
Inputs unconnected
-1
+1
A
Input Capacitance
5pF
POWER SUPPLIES
Supply Voltage
VDD
VSS = 0
2.7
5.5
V
Negative Power Supply
VSS
VDD = +2.7V
-2.7
0
V
Supply Voltage Difference
VDD - VSS
5.5
V
Active Supply Current
IDD
1.4
mA
VDD = +5V, VSS = 0
1.3
Standby Supply Current (Notes 3, 4)
ISTBY
VDD = +2.7V, VSS = -2.7V
1.3
mA
Shutdown Supply Current
ISHDN
(Note 3)
1
A
Power-Up Time
tPU
Click/pop suppression inactive
50
ms
Logic Supply Voltage
VLOGIC
VSS = 0
2.7
VDD
V
Logic Active Supply Current
IL
VRENCODEA = VRENCODEB = 0V
320
A
Logic Standby Supply Current
ILSTBY
(Note 4)
1
A
Logic Shutdown Current
ILSHDN
1A
LED INDICATORS (LEDIND0–LEDIND4,
MODEIND)
VLOGIC = 2.7V, ISINK = 10mA
0.4
Output Low Voltage
VOL
VLOGIC = 5.5V, ISINK = 10mA
0.2
V
Output Leakage Current
0.1
10
A
Output Capacitance
3pF
Maximum Sink Current
150
mA
Note 1: Parameters are 100% production tested at +85°C and limits through temperature are guaranteed by design.
Note 2: The device draws current in excess of the specified supply current when the digital inputs are driven with voltages between
(VDD - 0.5V) and (GND + 0.5V). See Digital Supply Current vs. Digital Input Voltage in the Typical Operating Characteristics.
Note 3: Shutdown refers to the SHDN input being asserted low. Standby refers to SHDN not being asserted and all I/O inactive.
Note 4: Supply current measured with the wiper position fixed.
_______________________________________________________________________________________
3
相關PDF資料
PDF描述
MAX5486EUG+ IC CNTRL VOL STEREO 24TSSOP
MAX5679ETJ+T IC GENERATOR PROG LCD 32TQFN
MAX6618AUB+ IC PECI TO I2C TRANSLATOR 10UMAX
MAX6621AUB+ IC TRANSL PECI TO I2C 10-UMAX
MAX7428EKA+T IC FILTER BUFFER VID SOT23-8
相關代理商/技術參數
參數描述
MAX5440EAG+ 功能描述:數字電位計 IC Stereo Vol Control w/Rotary Encoder RoHS:否 制造商:Maxim Integrated 電阻:200 Ohms 溫度系數:35 PPM / C 容差:25 % POT 數量:Dual 每 POT 分接頭:256 弧刷存儲器:Volatile 緩沖刷: 數字接口:Serial (3-Wire, SPI) 描述/功能:Dual Volatile Low Voltage Linear Taper Digital Potentiometer 工作電源電壓:1.7 V to 5.5 V 電源電流:27 uA 最大工作溫度:+ 125 C 安裝風格:SMD/SMT 封裝 / 箱體:TQFN-16 封裝:Reel
MAX5440EAG+T 功能描述:數字電位計 IC Stereo Vol Control w/Rotary Encoder RoHS:否 制造商:Maxim Integrated 電阻:200 Ohms 溫度系數:35 PPM / C 容差:25 % POT 數量:Dual 每 POT 分接頭:256 弧刷存儲器:Volatile 緩沖刷: 數字接口:Serial (3-Wire, SPI) 描述/功能:Dual Volatile Low Voltage Linear Taper Digital Potentiometer 工作電源電壓:1.7 V to 5.5 V 電源電流:27 uA 最大工作溫度:+ 125 C 安裝風格:SMD/SMT 封裝 / 箱體:TQFN-16 封裝:Reel
MAX5441ACUA 功能描述:數模轉換器- DAC RoHS:否 制造商:Texas Instruments 轉換器數量:1 DAC 輸出端數量:1 轉換速率:2 MSPs 分辨率:16 bit 接口類型:QSPI, SPI, Serial (3-Wire, Microwire) 穩定時間:1 us 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:SOIC-14 封裝:Tube
MAX5441ACUA+ 功能描述:數模轉換器- DAC 16-Bit Precision DAC RoHS:否 制造商:Texas Instruments 轉換器數量:1 DAC 輸出端數量:1 轉換速率:2 MSPs 分辨率:16 bit 接口類型:QSPI, SPI, Serial (3-Wire, Microwire) 穩定時間:1 us 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:SOIC-14 封裝:Tube
MAX5441ACUA+T 功能描述:數模轉換器- DAC 16-Bit Precision DAC RoHS:否 制造商:Texas Instruments 轉換器數量:1 DAC 輸出端數量:1 轉換速率:2 MSPs 分辨率:16 bit 接口類型:QSPI, SPI, Serial (3-Wire, Microwire) 穩定時間:1 us 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:SOIC-14 封裝:Tube
