(TA = +25°C, unless otherwise noted.) ATTENUAT" />
參數資料
型號： MAX5406EUM+
廠商： Maxim Integrated Products
文件頁數： 23/26頁
文件大?。?/td> 0K
描述： IC PROC AUDIO W/PB 48TSSOP
標準包裝： 39
類型： 音頻處理器
應用： 臺式音頻，卡拉 OK，TV
安裝類型： 表面貼裝
封裝/外殼： 48-TFSOP（0.240"，6.10mm 寬）
供應商設備封裝： 48-TSSOP
包裝： 管件
Typical Operating Characteristics
(TA = +25°C, unless otherwise noted.)
ATTENUATION vs. TAP POSITION
TAP POSITION
ATTENUATION
(dB)
toc01a
0
4
8
12
16
20
24
28
32
-70
-60
-50
-40
-30
-20
-10
0
VDD = VLOGIC = 5V, VSS = 0
VOLUP = 0dB
ATTENUATION vs. TAP POSITION
TAP POSITION
ATTENUATION
(dB)
MAX5406
toc01b
0
4
8
12
16
20
24
28
32
-70
-60
-50
-40
-30
-20
-10
0
VDD = VLOGIC = 2.7V, VSS = -2.7V
BAXANDALL CURVE
FREQUENCY (Hz)
GAIN
(dB)
MAX5406
toc02a
-15
-10
-5
0
5
10
15
10
100
1000
10,000
100,000
VDD = VLOGIC = 5V, VSS = 0
TREBLE = BASS
CCB_ = 10nF
CCT_ = 2.2nF
MAX5406
Audio Processor with Pushbutton Interface
6
_______________________________________________________________________________________
Note 1: All devices 100% production tested at TA = +85°C. Limits over the operating temperature range are guaranteed by design.
Note 2: Treble = bass = 0dB. CCB_ = open, CCT_ = short, left input signal = right input signal = +2V.
Note 3: See Tables 3 and 4 and Figure 7. VDD = +2.7V, VSS = -2.7V.
Note 4: Guaranteed by design.
Note 5: Measured with A-weighted filter.
Note 6: Supply current measured while attenuator position is fixed.
Note 7: Set _OUT = 0dB and shutdown device SHDN = 0. tWU is the time required for _OUT to reach 0dB after SHDN goes high.
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Power-Up Time
tPU
Power first applied, _OUT = -20dB
1
s
Wake-Up Time
tWU
From shutdown (Note 7)
1
s
Logic Supply Voltage
VLOGIC
DGND = 0, VLOGIC
≤ VDD
+2.7
VDD
V
Logic Active Supply Current
ILOGIC
No signal, one button pressed, remaining
logic inputs connected to VLOGIC or
unconnected
150
A
Logic Shutdown Supply Current
No signal, all logic inputs connected to
VLOGIC or unconnected, SHDN = DGND
(Note 6)
0.2
2
A
ELECTRICAL CHARACTERISTICS (continued)
(VDD = VLOGIC = +5.0V, VSS = 0, VBIAS = VCMSNS = VDD / 2, DGND = 0, ambience disabled, VAMBLI = VAMBRI = VBIAS, VR1_L =
VL1_L = VR2_L = VL2_L = external VBIAS, CCSUB = 0.15F, CCLS = CCRS = 1F, CCBL = CCBR = 3.3nF, CCTL = CCTR = 4.7nF, CBIAS =
0.1F, CCBIAS = 50F (see the Typical Application Circuit), TA = TMIN to TMAX unless otherwise specified. Typical values are at TA =
+25°C). (Note1)
