657
Fast Recovery Diodes (FRD)
MA3G695 (MA695)
Silicon planar type (cathode common)
For high-frequency rectification
I Features
Cathode common dual type
High reverse voltage V
R
Low forward voltage V
F
Fast reverse recovery time t
rr
I Absolute Maximum Ratings T
a = 25°C
Unit : mm
1 : Anode
2 : Cathode
(Common)
3 : Anode
TOP-3F(a) (TOP-3 Full-Pack Package)
Parameter
Symbol
Rating
Unit
Repetitive peak reverse voltage
VRRM
400
V
Non-repetitive peak reverse
VRSM
400
V
surge voltage
Average forward current
IF(AV)
20
A
Non-repetitive peak forward
IFSM
120
A
surge current*
Junction temperature
Tj
40 to +150
°C
Storage temperature
Tstg
40 to +150
°C
Note) * : Half sine-wave; 10 ms/cycle
Parameter
Symbol
Conditions
Min
Typ
Max
Unit
Repetitive peak reverse current
IRRM1
VRRM = 400 V, TC = 25
°C50
A
IRRM2
VRRM = 400 V, Tj = 150
°C10
mA
Forward voltage (DC)
VF
IF = 10 A, TC = 25°C1
V
Reverse recovery time*
trr
IF = 1 A, IR = 1 A
100
ns
Thermal resistance
Rth(j-c)
Direct current (between junction and case)
1.5
°C/W
Rth(j-a)
41.6
°C/W
I Electrical Characteristics T
a
= 25°C
Note) 1. Rated input/output frequency: 10 MHz
2. * : trr measuring circuit
Internal Connection
D.U.T
trr
0.1
× I
R
IF
IR
50
5.5
50
123
15.0
± 0.3
21.0
±
0.5
16.2
±
0.5
12.5
Solder
Dip
3.5
0.7
15.0
±
0.2
5.0
± 0.2
11.0
± 0.2
10.9
± 0.5
5.45
± 0.3
3
2
1
1.1
± 0.1
2.0
± 0.2
0.6
± 0.2
2.0
± 0.1
φ 3.2 ± 0.1
3.2
Note) The part number in the parenthesisi shows conbentional part number.
Ma
int
en
an
ce
/
Dis
co
nti
nu
ed
Maintenance/Discontinued
includes
following
four
Product
lifecy
cle
stage.
planed
maintenance
type
maintenance
type
planed
discontinued
typed
discontinued
type
Please
visit
following
URL
about
latest
information.
http://panasonic.net/sc/en
