DC and AC parameters
M41T00
20/25
Table 9. DC characteristics
Symbol
Parameter
Test condition(1)
1.
Valid for ambient operating temperature: TA = -40 to 85°C; VCC = 2.0 to 5.5V (except where otherwise
noted).
Min
Typ
Max
Unit
ILI
Input leakage current
0V = VIN = VCC
±1
A
ILO
Output leakage current
0V = VOUT = VCC
±1
A
ICC1
Supply current
Switch frequency =
100kHz
300
A
ICC2
RTC supply current
(standby)
SCL, SDA= VCC – 0.3V
70
A
VIL
Input low voltage
–0.3
0.3VCC
V
VIH
Input high voltage
0.7VCC
VCC+0.5
V
VOL
Output low voltage
IOL = 3.0mA
0.4
V
Output Low Voltage
(Open Drain)
FT/OUT
5.5
V
VBAT
(2)
2.
STMicroelectronics recommends the RAYOVAC BR1225 or BR1632 (or equivalent)as the battery supply.
Battery supply voltage
2.5(3)
3.
After switchover (VSO), VBAT(min) can be 2.0V for crystal with RS = 40K..
3.5(4)
4.
For rechargeable back-up, VBAT(max) may be considered VCC.
V
IBAT
Battery supply current
TA = 25°C, VCC = 0V
oscillator ON,
VBAT = 3V
0.8
1
A
Table 10. Crystal electrical characteristics
Symbol
Parameter (1) (2)
1.
Externally supplied if using the SO8 package. STMicroelectronics recommends the KDS DT-38:
1TA/1TC252E127, Tuning Fork Type (thru-hole) or the DMX-26S: 1TJS125FH2A212, (SMD) quartz crystal
for industrial temperature operations. KDS can be contacted at kouhou@kdsj.co.jp or http://www.kdsj.co.jp
for further information on this crystal type.
2.
Load capacitors are integrated within the M41T00. Circuit board layout considerations for the 32.768kHz
crystal of minimum trace lengths and isolation from RF generating signals should be taken into account.
Min
Typ
Max
Units
fO
Resonant frequency
32.768
kHz
RS
Series resistance
60
K
CL
Load capacitance
12.5
pF
