參數資料
型號： LTC2487CDE#PBF
廠商： Linear Technology
文件頁數： 5/32頁
文件大?。?/td> 0K
描述： IC ADC 16BIT DELTA SIG 14-DFN
標準包裝： 91
位數： 16
采樣率（每秒）： 15
數據接口： I²C，串行
轉換器數目： 1
功率耗散（最大）： 800µW
電壓電源： 單電源
工作溫度： 0°C ~ 70°C
安裝類型： 表面貼裝
封裝/外殼： 14-WFDFN 裸露焊盤
供應商設備封裝： 14-DFN-EP（4x3）
包裝： 管件
輸入數目和類型： 4 個單端，雙極；2 個差分，雙極
配用： DC1010A-C-ND - BOARD DELTA SIGMA ADC LTC2487
LTC2487
13
2487fd
ampliers. The remaining common mode input current
is eliminated by either balancing the differential input im-
pedances or setting the common mode input equal to the
common mode reference (see the Automatic Differential
Input Current Cancellation section). This unique architec-
ture does not require on-chip buffers, thereby enabling
signals to swing beyond ground and VCC. Moreover, the
cancellation does not interfere with the transparent offset
and full-scale auto-calibration and the absolute accuracy
(full scale + offset + linearity + drift) is maintained even
with external RC networks.
Power-Up Sequence
The LTC2487 automatically enters an internal reset state
when the power supply voltage, VCC, drops below a
threshold of approximately 2.0V. This feature guarantees
the integrity of the conversion result and input channel
selection.
When VCC rises above this threshold, the converter creates
an internal power-on-reset (POR) signal with a duration
of approximately 4ms. The POR signal clears all internal
registers. The conversion immediately following a POR
cycle is performed on the input channels IN+ = CH0 and
IN– = CH1 with simultaneous 50Hz/60Hz rejection, 1x
output rate, and gain = 1. The rst conversion following a
POR cycle is accurate within the specication of the device
if the power supply voltage is restored to (2.7V to 5.5V)
before the end of the POR interval. A new input channel,
rejection mode, speed mode, temperature selection or
gain can be programmed into the device during this rst
data input/output cycle.
Reference Voltage Range
This converter accepts a truly differential external reference
voltage. The absolute/common mode voltage range for the
REF+ and REF– pins covers the entire operating range of
the device (GND to VCC). For correct converter operation,
VREF must be positive (REF+ > REF–).
The LTC2487 differential reference input range is 0.1V to
VCC. For the simplest operation, REF+ can be shorted to
VCC and REF– can be shorted to GND. The converter out-
put noise is determined by the thermal noise of the front
end circuits and, as such, its value in nanovolts is nearly
constant with reference voltage. A decrease in reference
voltage will not signicantly improve the converter’s effec-
tive resolution. On the other hand, a decreased reference
will improve the converter’s overall INL performance.
Input Voltage Range
The analog inputs are truly differential with an absolute,
common mode range for the CH0-CH3 and COM input pins
extending from GND – 0.3V to VCC + 0.3V. Outside these
limits, the ESD protection devices begin to turn on and the
errors due to input leakage current increase rapidly. Within
these limits, the LTC2487 converts the bipolar differential
input signal VIN = IN+ – IN– (where IN+ and IN– are the
selected input channels), from –FS = –0.5 VREF/Gain
to +FS = 0.5 VREF/Gain where VREF = REF+ – REF–.
Outside this range, the converter indicates the overrange
or the underrange condition using distinct output codes
(see Table 1).
In order to limit any fault current, resistors of up to 5k
may be added in series with the input. The effect of series
resistance on the converter accuracy can be evaluated from
the curves presented in the Input Current/Reference Cur-
rent sections. In addition, series resistors will introduce a
temperature dependent error due to input leakage current.
A 1nA input leakage current will develop a 1ppm offset
error on a 5k resistor if VREF = 5V. This error has a very
strong temperature dependency.
APPLICATIONS INFORMATION
