External Components Description
(
Figure 1
) (Continued)
Components
4.
Functional Description
C
S
Supply bypass capacitor which provides power supply filtering. Refer to the
Power Supply Bypassing
section for information concerning proper placement and selection of the supply bypass capacitor.
Bypass pin capacitor which provides half-supply filtering. Refer to the section,
Proper Selection of External
Components
, for information concerning proper placement and selection of C
B
.
This output coupling capacitor blocks DC voltage while coupling the AC audio signal to the headphone
speaker. Combined with R
L
, the headphone impedance, it creates a high pass filter at f
c
= 1/(2
π
R
L
C
OUT
).
Refer to the section,
Proper Selection of External Components
for an explanation of how to determine the
value of C
OUT
.
This is the pull up resistor to activate headphone operation when a headphone plug is plugged into the
headphone jack.
This is the current limiting resistor for the headphone input pin.
This is the pull down resistor to de-activate headphone operation when no headphone is plugged into the
headphone jack.
5.
C
B
6.
C
OUT
7.
R
PU
8.
9.
R
S
R
PD
Typical Performance Characteristics
THD+N vs Frequency
at V
DD
= 5V, 8
R
L
, and PWR = 250mW
THD+N vs Frequency
at V
DD
= 3.3V, 8
R
L
, and PWR = 150mW
20012737
20012738
THD+N vs Frequency
at V
DD
= 2.6V, 8
R
L
, and PWR = 100mW
THD+N vs Frequency
at V
DD
= 2.6V, 4
R
L
, and PWR = 100mW
20012739
20012740
L
www.national.com
5
