ABSOLUTE MAXIMUM RATING
Symbol
V
i
DC InputVoltage
Parameter
Value
30
35
Unit
V
V
V
o
= 3.3V to 9 V
V
o
= 12 V to 15V
V
o
= 18 V to 24V
40
100
V
I
o
OutputCurrent
mA
P
tot
T
stg
T
op
Power Dissipation
StorageTemperature Range
Operating Junction TemperatureRangeForL78L00C, L78L00AC
ForL78L00AB
(*) Our SO-8 package used for Voltage Regulators is modified internally to have pins 2, 3, 6 and 7 electrically commoned to the die attach
flag. This particular frame decreases the total thermal resistance of the package and increases its ability to dissipate power when an
appropriatearea of copper on the printed circuit board is available for heatsinking. The external dimensions are the same as forthe standard
SO-8
Internally limited (*)
- 40 to 150
0 to 125
- 40 to 125
o
C
o
C
o
C
TESTCIRCUITS
THERMALDATA
Symbol
Parameter
SO-8
TO-92
SOT-89
Unit
o
C/W
o
C/W
R
thj-case
R
thj-amb
(*) Considering 6cm
2
of copper Board heat-sink
Thermal Resistance Junction-case
Thermal Resistance Junction-ambient
Max
Max
20
55 (*)
200
12
L78L00
2/19
