L7200
6/23
THERMAL DATA
* In typical application with multilayer 120x120mm Printed Circuit Board.
RECOMMENDED OPERATING CONDITIONS
ELECTRICAL CHARACTERISTCS
All specifications are for 0<Tamb<70°C, VCC=12V, VDD=5V, unless otherwise noted.
Symbol
Parameter
Value
Unit
θ(jc)
Thermal resistance Junction to case
≈11
°C/Watt
θ(ja)*
Thermal resistance Junction to ambient
≈40
°C/Watt
Ptot*
Maximum Total Power Dissipation
≈2.0
Watt
Tstg,Tj
Maximum storage/junction temperature
-40 to 150
°C
Symbol
Parameter
Value
Unit
Vdd
Supply Voltage
10.8 to 13.2
V
Vcc
Logic Supply Voltage
4.5 to 5.5
V
Tamb
Operating Ambient Temperature
0 to 70
°C
Tj
Junction Temperature
0 to 125
°C
Symbol
Parameter
Test Condition
Min.
Typ.
Max.
Unit
POWER SUPPLIES
VCC
12V supply
10.8
13.2
V
IVCC
Vcc Current
SPINDLE + VCM
TBD
mA
SPINDLE ONLY
TBD
mA
VCM ONLY
TBD
mA
Vrectified
Vcc supply rectified
3.5
13.2
V
Vdd
5V supply
4.5
5.5
V
Ivdd
5V supply
SPINDLE + VCM
TBD
mA
SPINDLE ONLY
TBD
mA
VCM ONLY
TBD
mA
THERMAL SENSING
TSD
SHUTDOWN TEMPERATURE
150
180
°C
THYS
HYSTERESIS
60
°C
TEW
EARLY WARNING
TSD-
25
°C
