參數資料
型號： L6226QTR
廠商： STMICROELECTRONICS
元件分類： 運動控制電子
英文描述： BRUSH DC MOTOR CONTROLLER, QCC32
封裝： 5 X 5 MM, 1 MM HEIGHT, 0.50 MM PITCH, ROHS COMPLIANT, VFQFPN-32
文件頁數： 17/29頁
文件大?。?/td> 480K
代理商： L6226QTR
Thermal management
L6226Q
24/29
Doc ID 14335 Rev 5
8
Thermal management
In most applications the power dissipation in the IC is the main factor that sets the maximum
current that can be deliver by the device in a safe operating condition. Therefore, it has to be
taken into account very carefully. Besides the available space on the PCB, the right package
should be chosen considering the power dissipation. Heat sinking can be achieved using
copper on the PCB with proper area and thickness. For instance, using a VFQFPN32L 5x5
package the typical Rth(JA) is about 42 °C/W when mounted on a double-layer FR4 PCB with
a dissipating copper surface of 0.5 cm2 on the top side plus 6 cm2 ground layer connected
through 18 via holes (9 below the IC).
相關PDF資料
PDF描述
L6226Q BRUSH DC MOTOR CONTROLLER, 2.8 A, QCC32
L6227N STEPPER MOTOR CONTROLLER, 2.8 A, PDIP24
L6228Q STEPPER MOTOR CONTROLLER, 2.8 A, QCC32
L6228QTR STEPPER MOTOR CONTROLLER, QCC32
L6229D BRUSHLESS DC MOTOR CONTROLLER, 2.8 A, PDSO24
相關代理商/技術參數
參數描述
L6227 制造商:STMICROELECTRONICS 制造商全稱:STMicroelectronics 功能描述:DMOS DUAL FULL BRIDGE DRIVER WITH PWM CURRENT CONTROLLER
L6227D 功能描述:馬達/運動/點火控制器和驅動器 Dual Full Bridge RoHS:否 制造商:STMicroelectronics 產品:Stepper Motor Controllers / Drivers 類型:2 Phase Stepper Motor Driver 工作電源電壓:8 V to 45 V 電源電流:0.5 mA 工作溫度:- 25 C to + 125 C 安裝風格:SMD/SMT 封裝 / 箱體:HTSSOP-28 封裝:Tube
L6227DTR 功能描述:馬達/運動/點火控制器和驅動器 Dual Full Bridge RoHS:否 制造商:STMicroelectronics 產品:Stepper Motor Controllers / Drivers 類型:2 Phase Stepper Motor Driver 工作電源電壓:8 V to 45 V 電源電流:0.5 mA 工作溫度:- 25 C to + 125 C 安裝風格:SMD/SMT 封裝 / 箱體:HTSSOP-28 封裝:Tube
L6227N 功能描述:馬達/運動/點火控制器和驅動器 Dual Full Bridge RoHS:否 制造商:STMicroelectronics 產品:Stepper Motor Controllers / Drivers 類型:2 Phase Stepper Motor Driver 工作電源電壓:8 V to 45 V 電源電流:0.5 mA 工作溫度:- 25 C to + 125 C 安裝風格:SMD/SMT 封裝 / 箱體:HTSSOP-28 封裝:Tube
L6227PD 功能描述:馬達/運動/點火控制器和驅動器 Dual Full Bridge RoHS:否 制造商:STMicroelectronics 產品:Stepper Motor Controllers / Drivers 類型:2 Phase Stepper Motor Driver 工作電源電壓:8 V to 45 V 電源電流:0.5 mA 工作溫度:- 25 C to + 125 C 安裝風格:SMD/SMT 封裝 / 箱體:HTSSOP-28 封裝:Tube
