These transparent plastic packages are extremely sensitive to reflow soldering conditions and must
on no account be processed through more than one soldering cycle or subjected to infrared reflow
soldering with peak temperature exceeding 217
°
C
±
10
°
C measured in the atmosphere of the reflow
oven. The package body peak temperature must be kept as low as possible.
These packages are not suitable for wave soldering. On versions with the heatsink on the bottom
side, the solder cannot penetrate between the printed-circuit board and the heatsink. On versions with
the heatsink on the top side, the solder might be deposited on the heatsink surface.
If wave soldering is considered, then the package must be placed at a 45
°
angle to the solder wave
direction. The package footprint must incorporate solder thieves downstream and at the side corners.
Wave soldering is suitable for LQFP, QFP and TQFP packages with a pitch (e) larger than 0.8 mm; it
is definitely not suitable for packages with a pitch (e) equal to or smaller than 0.65 mm.
Wave soldering is suitable for SSOP, TSSOP, VSO and VSOP packages with a pitch (e) equal to or
larger than 0.65 mm; it is definitely not suitable for packages with a pitch (e) equal to or smaller than
0.5 mm.
Image sensor packages in principle should not be soldered. They are mounted in sockets or delivered
pre-mounted on flex foil. However, the image sensor package can be mounted by the client on a flex
foil by using a hot bar soldering process. The appropriate soldering profile can be provided on
request.
Hot bar soldering or manual soldering is suitable for PMFP packages.
[4]
[5]
[6]
[7]
[8]
[9]
21. Revision history
Table 48:
Rev
02
Revision history
CPCN
20040504
Date
Description
Product data (9397 750 11689)
Modifications:
Removed information on bus-power and hybrid-power
Changed active LOW pin symbol representation from overscore (for example, NAME) to
underscore N (NAME_N)
Globally changed V
CC(5V0)
to V
REF(5V0)
Table 2
: updated
Updated
Section 9.1.3
Updated
Table 7
Table 34
and
Table 35
: changed the value of V
REF(5V0)
Globally changed the value of T
amb
Table 36
: removed I
CC(5V0)
Updated
Figure 16
Updated
Figure 19
and
Figure 20
.
Preliminary data (9397 750 10689)
-
01
20030625
-
