HD74LV1G125A
Bus Buffer Gate with 3–state Output
ADE-205-323C (Z)
4th. Edition
April 2001
Description
The HD74LV1G125A has a bus buffer gate with 3–state output in a 5 pin package. Output is disabled
when the associated output enable (
OE
) input is high. To ensure the high impedance state during power up
or power down,
OE
should be connected to V
CC
through a pull-down resistor; the minimum value of the
resistor is determined by the current souring capability of the driver. Low voltage and high speed operation
is suitable for the battery powered products (e.g., notebook computers), and the low power consumption
extends the battery life.
Features
The basic gate function is lined up as hitachi uni logic series.
Supplied on emboss taping for high speed automatic mounting.
Electrical characteristics equivalent to the HD74LV125A
Supply voltage range : 1.65 to 5.5 V
Operating temperature range : –40 to +85
°
C
All inputs V
IH
(Max.) = 5.5 V (@V
CC
= 0 V to 5.5 V)
All outputs V
O
(Max.) = 5.5 V (@V
CC
= 0 V, Output : Z)
Output current
±
6 mA (@V
CC
= 3.0 V to 3.6 V),
±
12 mA (@V
CC
= 4.5 V to 5.5 V)
All the logical input has hysteresis voltage for the slow transition.
