參數資料
| 型號： | FSA8049UCX |
| 廠商： | Fairchild Semiconductor |
| 文件頁數： | 3/8頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC AUDIO JACK DETECT SW 9-WLCSP |
| 標準包裝： | 1 |
| 類型： | 音頻插孔探測器和配置開關 |
| 應用： | MP3 播放器，便攜式媒體播放器 |
| 安裝類型： | * |
| 封裝/外殼： | * |
| 供應商設備封裝： | * |
| 包裝： | 標準包裝 |
| 其它名稱： | FSA8049UCXFSDKR |
2011 Fairchild Semiconductor Corporation
www.fairchildsemi.com
FSA8049 Rev. 1.0.2
3
FSA8049
—
Audio
Jack
Detect
ion
and
Confi
guration,
MIC/GND
Cr
oss
point
Switch
Absolute Maximum Ratings
Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be operable
above the recommended operating conditions and stressing the parts to these levels is not recommended. In addition,
extended exposure to stresses above the recommended operating conditions may affect device reliability. The absolute
maximum ratings are stress ratings only.
Symbol
Parameter
Min.
Max.
Unit
v
Supply Voltage from Battery
-0.5
6.0
V
VSW
Switch I/O Voltage
-0.5
VCC+0.5
V
IIK
Input Clamp Diode Current
-50
mA
ISW
Switch I/O Current (Continuous)
(2)
50
mA
TSTG
Storage Temperature Range
-65
+150
°C
TJ
Maximum Junction Temperature
+150
°C
TL
Lead Temperature (Soldering, 10 Seconds)
+260
°C
ESD
IEC 61000-4-2 System ESD
Air Gap
15
kV
Contact
8
Human Body Model, JEDEC JESD22-A114
GND/MICn vs. GND
11
VDD vs. GND
16
All Pins
7
Charged Device Model, JEDEC JESD22-C101 All Pins
1.5
Note:
2.
The input and output negative ratings may be exceeded if the input and output diode current ratings are observed.
Recommended Operating Conditions
The Recommended Operating Conditions table defines the conditions for actual device operation. Recommended operating
conditions are specified to ensure optimal performance to the datasheet specifications. Fairchild does not recommend
exceeding them or designing to Absolute Maximum Ratings.
Symbol
Parameter
Min.
Max.
Unit
VDD
Supply Voltage
2.5
4.4
V
VEN
Enable Input Voltage
0
VDD
V
TA
Operating Temperature
-40
+85
C
