www.fairchildsemi.com
Features
Three video anti-aliasing or reconstruction filters
2:1 Mux inputs for YPbPr / RGB or YPbPr / YC-CV inputs
Supports D1, D2, D3 and D4 video D-connector
(EIAJ CP-4120)
Selectable 8MHz/15MHz/30MHz 6th order filters plus
bypass for SD (480i), Progressive (480p) and HD
(1080i/ 720p)
AC-coupled inputs include DC restore /bias circuitry
All outputs can drive AC or DC coupled 75
provide either 0dB or 6dB of gain
0.6% differential gain, 0.4° differential phase
Lead-free packaging
loads and
Applications
Progressive scan
Cable set top boxes
Satellite set top boxes
DVD players
HDTV
Personal Video Recorders (PVR)
Video On Demand (VOD)
Description
The FMS6407 offers comprehensive filtering for TV, set top
box or DVD applications. This part consists of a triple 6th
order filter with selectable 30MHz, 15MHz, or 8MHz cutoff
frequencies. The filters may also be bypassed so that the
bandwidth is limited only by the output amplifiers.
A 2 to 1 multiplexer is provided on each filter channel.
The triple filters are intended for YPbPr, RGB and YC-CV
signals. The DC clamp levels are set according to the input
mux selection and the CV_SEL control input. YPbPr sync
tips are clamped to 250mV, 1.125V and 1.125V respectively
while RGB sync tips are all clamped to 250mV. CV mode
clamps Y and CV to 250mV while C is clamped to 1.l25V.
Sync clamp timing can be derived from the Y or Green input
channel or from the external SYNC_IN pin.
All channels nominally accept AC coupled 1Vpp signals.
Selectable 0dB or 6dB gain allows the outputs to drive 1Vpp
or 2Vpp signals into AC or DC coupled terminated loads
with a 1Vpp input. Input signals cannot exceed 1.5Vpp and
outputs cannot exceed 2.5Vpp.
The FMS6407 draws 525mW from a single 5.0V supply.
FMS6407
Triple Video Drivers with Selectable
HD/Progressive/SD/Bypass Filters
Ordering Information
Temperature range for all parts: 0°C to +70°C.
Contact your local Fairchild Semiconductor
distributor for additional product information
Model
Part Number
Lead
Free
Package
Container
Pack Qty
FMS6407
FMS6407MTC20_NL
TSSOP-20
Tube
94
FMS6407
FMS6407MTC20X_NL
TSSOP-20
Tape and Reel
2500
May
21,
2004
2004 Fairchild Semiconductor Corporation
DISCLAIMER
FAIRCHILD SEMICONDUCTOR RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICES TO ANY PRODUCTS HEREIN TO IMPROVE RELIABILITY, FUNCTION
OR DESIGN. FAIRCHILD DOES NOT ASSUME ANY LIABILITY ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT OR CIRCUIT DESCRIBED HEREIN; NEITHER DOES
IT CONVEY ANY LICENSE UNDER ITS PATENT RIGHTS, NOR THE RIGHTS OF OTHERS.
LIFE SUPPORT POLICY
FAIRCHILD’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS WRITTEN
APPROVAL OF THE PRESIDENT OF FAIRCHILD SEMICONDUCTOR CORPORATION. As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into the body, or (b) support or sustain life, and (c) whose failure to per
form when properly used in accordance with instructions for use provided in the labeling,
can be reasonably expected to result in a significant injury of the user.
2. A critical component in any component of a life support device or system whose failure
to perform can be reasonably expected to cause the failure of the life support device or
system, or to affect its safety or effectiveness.
