April 2000
PRELIMINARY
2000 Fairchild Semiconductor Corporation
FDS6609A Rev B(W)
FDS6609A
P-Channel Logic Level PowerTrench
ò
MOSFET
General Description
This P-Channel Logic Level MOSFET is produced
using
Fairchild
Semiconductor's
PowerTrench process that has been especially tailored
to minimize on-state resistance and yet maintain
superior switching performance.
advanced
These devices are well suited for low voltage and
battery powered applications where low in-line power
loss and fast switching are required.
Applications
DC/DC converter
Load switch
Motor Drive
Features
–6.3 A, –30 V. R
DS(ON)
= 0.032
@ V
GS
= -10 V
R
DS(ON)
= 0.05
@ V
GS
= -4.5 V
Low gate charge
Fast switching speed
High performance trench technology for extremely
low R
DS(ON)
High power and current handling capability
S
D
S
S
SO-8
D
D
D
G
4
3
2
1
5
6
7
8
Absolute Maximum Ratings
T
A
=25
o
C unless otherwise noted
Symbol
Parameter
V
DSS
Drain-Source Voltage
V
GSS
Gate-Source Voltage
I
D
Drain Current
– Continuous
– Pulsed
Power Dissipation for Single Operation
P
D
Ratings
–30
±
20
-6.3
-40
2.5
1.2
1.0
-55 to +150
Units
V
V
A
(Note 1a)
(Note 1a)
(Note 1b)
(Note 1c)
W
T
J
, T
STG
Operating and Storage Junction Temperature Range
°
C
Thermal Characteristics
R
θ
JA
Thermal Resistance, Junction-to-Ambient
R
θ
JC
Thermal Resistance, Junction-to-Case
(Note 1a)
50
25
°
C/W
°
C/W
(Note 1)
Package Marking and Ordering Information
Device Marking
Device
FDS6609A
FDS6609A
Reel Size
13’’
Tape width
12mm
Quantity
2500 units
F
