參數資料
| 型號： | FDP6644 |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | JFETs |
| 英文描述： | 30V N-Channel PowerTrench MOSFET |
| 中文描述： | 50 A, 30 V, 0.0105 ohm, N-CHANNEL, Si, POWER, MOSFET, TO-220AB |
| 封裝： | TO-220, 3 PIN |
| 文件頁數： | 1/5頁 |
| 文件大?。?/td> | 80K |
| 代理商： | FDP6644 |
June 2001
2001 Fairchild Semiconductor Corporation
FDP6644 Rev C(W)
FDP6644/FDB6644
30V N-Channel PowerTrench
MOSFET
General Description
This
specifically to improve the overall efficiency of DC/DC
converters using either synchronous or conventional
switching PWM controllers.
N-Channel
MOSFET
has
been
designed
These MOSFETs feature faster switching and lower
gate charge than other MOSFETs with comparable
RDS
(ON)
specifications.
The result is a MOSFET that is easy and safer to drive
(even at very high frequencies), and DC/DC power
supply designs with higher overall efficiency.
Features
50 A, 30 V.
R
DS(ON)
= 8.5 m
@ V
GS
= 10 V
R
DS(ON)
= 10.5 m
@ V
GS
= 4.5 V
Low gate charge (27 nC typical)
Fast switching speed
High performance trench technology for extremely
low R
DS(ON)
175
°
C maximum junction temperature rating
S
G
D
TO-220
FDP Series
D
G
S
TO-263AB
FDB Series
S
G
D
Absolute Maximum Ratings
T
A
=25
o
C unless otherwise noted
Symbol
Parameter
V
DSS
Drain-Source Voltage
V
GSS
Gate-Source Voltage
I
D
Drain Current
– Continuous
– Pulsed
P
D
Total Power Dissipation @ T
C
= 25
°
C
Ratings
30
±
16
50
150
83
0.55
-65 to +175
Units
V
V
A
A
W
W/
°
C
°
C
(Note 1)
(Note 1)
Derate above 25
°
C
T
J
, T
STG
Operating and Storage Junction Temperature Range
Thermal Characteristics
R
θ
JC
Thermal Resistance, Junction-to-Case
R
θ
JA
Thermal Resistance, Junction-to-Ambient
1.8
62.5
°
C/W
°
C/W
Package Marking and Ordering Information
Device Marking
Device
FDB6644
FDB6644
FDP6644
FDP6644
Reel Size
13’’
Tube
Tape width
24mm
n/a
Quantity
800 units
45
F
