Data Sheet
April 1999
W3030 3 V Dual-Mode IF Cellular Receiver
Lucent Technologies Inc.
7
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are
absolute stress ratings only. Functional operation of the device is not implied at these or any other conditions in
excess of those given in the operations sections of the data sheet. Exposure to absolute maximum ratings for
extended periods can adversely affect device reliability.
Parameter
Min
Max
Unit
Ambient Operating Temperature
–35
100
°C
Storage Temperature
–65
150
°C
Lead Temperature (soldering, 10 s)
—
300
°C
Positive Supply Voltage
0
4.5
Vdc
Power Dissipation
—
650
mW
Output Current (continuous)
—
160
mA
ac Peak-to-peak Input Voltage
0
VCC
Vdc
Enable Input Voltage
–0.3
VCC + 0.4
Vdc
VCM, AGC Input Voltage
–0.3
VCC + 0.4
Vdc
Handling Precautions
Although protection circuitry has been designed into this device, proper precautions should be taken to avoid
exposure to electrostatic discharge (ESD) during handling and mounting. Lucent Technologies Microelectronics
Group employs a human-body model (HBM) and a charged-device model (CDM) for ESD-susceptibility testing
and protection design evaluation. ESD voltage thresholds are dependent on the circuit parameters used to define
the model. No industry-wide standard has been adopted for CDM. However, a standard HBM (resistance =
1500
, capacitance = 100 pF) is widely used and, therefore, can be used for comparison purposes. The HBM
ESD threshold presented here was obtained by using these circuit parameters:
W3030 ESD Threshold Voltage
ESD Model
Rating
HBM
≥1500 V
CDM
≥1500 V
