參數資料
| 型號： | EFM32GG990F1024 |
| 廠商： | Energy Micro |
| 文件頁數： | 50/73頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC MCU 32BIT 1024KB FLASH BGA112 |
| 標準包裝： | 1 |
| 系列： | Giant Gecko |
| 核心處理器： | ARM? Cortex?-M3 |
| 芯體尺寸： | 32-位 |
| 速度： | 48MHz |
| 連通性： | EBI/EMI，I²C，IrDA，智能卡，SPI，UART/USART，USB |
| 外圍設備： | 欠壓檢測/復位，DMA，LCD，POR，PWM，WDT |
| 輸入/輸出數： | 87 |
| 程序存儲器容量： | 1MB（1M x 8） |
| 程序存儲器類型： | 閃存 |
| RAM 容量： | 128K x 8 |
| 電壓 - 電源 (Vcc/Vdd)： | 1.85 V ~ 3.8 V |
| 數據轉換器： | A/D 8x12b，D/A 2x12b |
| 振蕩器型： | 外部 |
| 工作溫度： | -40°C ~ 85°C |
| 封裝/外殼： | 112-LFBGA |
| 包裝： | 標準包裝 |
| 其它名稱： | 914-1051-6 |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁第36頁第37頁第38頁第39頁第40頁第41頁第42頁第43頁第44頁第45頁第46頁第47頁第48頁第49頁當前第50頁第51頁第52頁第53頁第54頁第55頁第56頁第57頁第58頁第59頁第60頁第61頁第62頁第63頁第64頁第65頁第66頁第67頁第68頁第69頁第70頁第71頁第72頁第73頁
Preliminary
...the world's most energy friendly microcontrollers
2013-06-28 - EFM32GG990FXX - d0046_Rev1.10
54
www.energymicro.com
Alternate
LOCATION
Functionality
0
1
2
3
4
5
6
Description
ETM_TD1
PD3
PD13
PD3
PA3
Embedded Trace Module ETM data 1.
ETM_TD2
PD4
PB15
PD4
PA4
Embedded Trace Module ETM data 2.
ETM_TD3
PD5
PA5
Embedded Trace Module ETM data 3.
GPIO_EM4WU0
PA0
Pin can be used to wake the system up from EM4
GPIO_EM4WU1
PA6
Pin can be used to wake the system up from EM4
GPIO_EM4WU2
PC9
Pin can be used to wake the system up from EM4
GPIO_EM4WU3
PF1
Pin can be used to wake the system up from EM4
GPIO_EM4WU4
PF2
Pin can be used to wake the system up from EM4
GPIO_EM4WU5
PE13
Pin can be used to wake the system up from EM4
HFXTAL_N
PB14
High Frequency Crystal negative pin. Also used as exter-
nal optional clock input pin.
HFXTAL_P
PB13
High Frequency Crystal positive pin.
I2C0_SCL
PA1
PD7
PC7
PD15
PC1
PF1
PE13
I2C0 Serial Clock Line input / output.
I2C0_SDA
PA0
PD6
PC6
PD14
PC0
PF0
PE12
I2C0 Serial Data input / output.
I2C1_SCL
PC5
PB12
PE1
I2C1 Serial Clock Line input / output.
I2C1_SDA
PC4
PB11
PE0
I2C1 Serial Data input / output.
LCD_BCAP_N
PA13
LCD voltage booster (optional), boost capacitor, negative
pin. If using the LCD voltage booster, connect a 22 nF ca-
pacitor between LCD_BCAP_N and LCD_BCAP_P.
LCD_BCAP_P
PA12
LCD voltage booster (optional), boost capacitor, positive
pin. If using the LCD voltage booster, connect a 22 nF ca-
pacitor between LCD_BCAP_N and LCD_BCAP_P.
LCD_BEXT
PA14
LCD voltage booster (optional), boost output. If using the
LCD voltage booster, connect a 1 uF capacitor between
this pin and VSS.
An external LCD voltage may also be applied to this pin if
the booster is not enabled.
If AVDD is used directly as the LCD supply voltage, this
pin may be left unconnected or used as a GPIO.
LCD_COM0
PE4
LCD driver common line number 0.
LCD_COM1
PE5
LCD driver common line number 1.
LCD_COM2
PE6
LCD driver common line number 2.
LCD_COM3
PE7
LCD driver common line number 3.
LCD_SEG0
PF2
LCD segment line 0. Segments 0, 1, 2 and 3 are con-
trolled by SEGEN0.
LCD_SEG3
PF5
LCD segment line 3. Segments 0, 1, 2 and 3 are con-
trolled by SEGEN0.
LCD_SEG4
PE8
LCD segment line 4. Segments 4, 5, 6 and 7 are con-
trolled by SEGEN1.
LCD_SEG5
PE9
LCD segment line 5. Segments 4, 5, 6 and 7 are con-
trolled by SEGEN1.
LCD_SEG6
PE10
LCD segment line 6. Segments 4, 5, 6 and 7 are con-
trolled by SEGEN1.
LCD_SEG7
PE11
LCD segment line 7. Segments 4, 5, 6 and 7 are con-
trolled by SEGEN1.
LCD_SEG8
PE12
LCD segment line 8. Segments 8, 9, 10 and 11 are con-
trolled by SEGEN2.
LCD_SEG9
PE13
LCD segment line 9. Segments 8, 9, 10 and 11 are con-
trolled by SEGEN2.
LCD_SEG10
PE14
LCD segment line 10. Segments 8, 9, 10 and 11 are con-
trolled by SEGEN2.
