D
S
29001 Rev. A-2
1 of 2
D1G-D7G
D1G - D7G
1.0A GLASS PASSIVATED RECTIFIER
Features
A
A
B
C
D
T-1
Min
Dim
A
B
C
D
Max
25.40
2.60
3.20
0.53
0.64
2.20
2.60
All Dimensions in mm
Maximum Ratings and Electrical Characteristics
@ T
A
= 25 C unless otherwise specified
Glass Passivated Die Construction
Diffused Junction
High Current Capability and Low Forward
Voltage Drop
Surge Overload Rating to 30A Peak
Plastic Material: UL Flammability
Classification Rating 94V-0
Mechanical Data
Case: Molded Plastic
Terminals: Plated Leads Solderable per
MIL-STD-202, Method 208
Polarity: Cathode Band
Marking: Type Number
Weight: 0.13 grams (approx.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
D1G
D2G
D3G
D4G
D5G
D6G
D7G
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
(Note 1)
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave superimposed on rated load
(JEDEC Method)
Forward Voltage
50
100
200
400
600
800
1000
V
35
70
140
280
420
560
700
V
@ T
A
= 75 C
I
O
1.0
A
I
FSM
30
A
@ I
F
= 1.0A
@ T
A
= 25 C
@ T
A
= 100 C
V
FM
1.0
5.0
50
2.0
8.0
100
V
Peak Reverse Current
at Rated DC Blocking Voltage
Reverse Recovery Time (Note 3)
Typical Junction Capacitance (Note 2)
Typical Thermal Resistance Junction to Ambient
Operating and Storage Temperature Range
I
RM
A
t
rr
C
j
s
pF
K/W
C
R
JA
T
j,
T
STG
-65 to +150
Notes:
1. Valid provided that leads are maintained at ambient temperature at a distance of 9.5mm from the case.
2. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
3. Measured with I
F
= 0.5A, I
R
= 1A, I
rr
= 0.25A.
