ConnectCorefor i.MX51
2011DigiInternational,Inc.
15
18
-
GND
-
19
WLAN
WLAN_TDO
WLAN: TDO
Not Used
20
WLAN
WLAN_TCK
WLAN: TCK
Not Used
21
WLAN
WLAN_TDI
WLAN: TDI
Not Used
22
WLAN
WLAN_TMS
WLAN: TMS
Not Used
23
WLAN
WLAN_LED
WLAN: LED_ON
WLAN LED
24
WLAN
RS_BT_PRIORITY
WLAN: BT_PRIORITY
Not Used
25
WLAN
RS_WLAN_ACTIVE
WLAN: WLAN_ACTIVE
Not Used
26
WLAN
RS_BT_ACTIVE
WLAN: BT_ACTIVE
Not Used
27
LVIO
BOOT_MODE0
i.MX51: BOOT_MODE0
Boot Mode selection
Boot configuration not
available in EA Kit
28
GPIO33
WLAN_DISABLE#
WLAN Power Supply Switch
WLAN Disable Jumper (J17)
This signal switch ON/OFF
the supply of WLAN
29
LVIO
BOOT_MODE1
i.MX51: BOOT_MODE1
Boot Mode selection
Boot configuration not
available in EA Kit
30
-
VLIO
MC13892: BATT
Battery supply
31
-
VLIO
MC13892: BATT
Battery supply
32
-
VCHRG
MC13892: CHRGRAW
Charger supply
33
-
+2.775V
-
34
-
VCHRG
MC13892: CHRGRAW
Charger supply
35
-
+2.775V
-
36
-
+2.775V
-
37
PMIC_GPO
MC13892_GPO1
MC13892: GPO1
Reserved
38
-
+2.775V
-
39
PMIC_PWRON
PMIC_PWRON1
MC13892: PWRON1
Connected to Power Button (S11)
Suspend / Wake-up button
40
PMIC_STDBY
PMIC_STDBY_REQ
i.MX51: PMIC_STBY_REQ
MC13892: STANDBY
Reserved
Output from i.MX51 to put
MC13892 in low power
mode
41
PMIC_INT
PMIC_INT_REQ
i.MX51: PMIC_INT_REQ
Reserved
This high-priority interrupt
input on i.MX51 is not used.
The output interrupt from
PMIC is connected to
standard interrupt GPIO_5 on
i.MX51.
42
PMIC_PWGTDRV
PWRGTDRV1
MC13892: PWRGTDRV1
Not used
43
PMIC_LED
CHRGLED
MC13892: CHRGLED
Battery Charging LED
Pin
I/O Type
Signal name
Use on module
Use on development board
Comments
