BUL381D
BUL382D
HIGH VOLTAGE FAST-SWITCHING
NPN POWER TRANSISTORS
I
SGS-THOMSON PREFERRED SALESTYPES
I
HIGH VOLTAGECAPABILITY
I
LOW SPREADOF DYNAMIC PARAMETERS
I
MINIMUMLOT-TO-LOT SPREAD FOR
RELIABLEOPERATION
I
VERYHIGH SWITCHING SPEED
I
LARGERBSOA
I
INTEGRATED ANTIPARALLEL
COLLECTOR-EMITTER DIODE
APPLICATIONS
I
ELECTRONIC TRANSFORMERS FOR
HALOGEN LAMPS
I
ELECTRONICBALLASTSFOR
FLUORESCENT LIGHTING
I
SWITCH MODE POWER SUPPLIES
DESCRIPTION
The BUL381D and BUL382D are manufactured
using
high
voltage
Multi
technology for high switching speeds and high
voltage capability.
The BUL series is designed for use in lighting
applications and low cost switch-mode power
supplies.
Epitaxial
Planar
INTERNAL SCHEMATIC DIAGRAM
July 1997
ABSOLUTE MAXIMUM RATINGS
Symbol
V
CES
V
CEO
V
EBO
I
C
I
CM
I
B
I
BM
P
tot
T
stg
T
j
Parameter
Value
800
400
9
5
8
2
4
70
-65 to 150
150
Unit
V
V
V
A
A
A
A
W
o
C
o
C
Collector-Emitter Voltage (V
BE
= 0)
Collector-Emitter Voltage (I
B
= 0)
Emitter-Base Voltage (I
C
= 0)
Collector Current
Collector Peak Current (t
p
< 5 ms)
Base Current
Base Peak Current (t
p
< 5 ms)
Total Dissipation at T
c
= 25
o
C
Storage Temperature
Max. Operating Junction Temperature
1
2
3
TO-220
1/6
