APT60D30LCT(G)
0
APT30M36LLL
4
3
1
2
5
5
Zero
1
2
3
4
di
F
/dt - Rate of Diode Current Change Through Zero Crossing.
I
F
- Forward Conduction Current
I
RRM
- Maximum Reverse Recovery Current.
trr - Reverse
R
ecovery Time, measured from zero crossing where
diode
current goes from positive to negative, to the point at which the straight
line through I
RRM
and 0.25 I
RRM
passes through zero.
Qrr - Area Under the Curve Defined by I
RRM
and trr.
Figure 9. Diode Test Circuit
Figure 10, Diode Reverse Recovery Waveform and Definitions
0.25 IRRM
PEARSON 2878
CURRENT
TRANSFORMER
di
F
/dt Adjust
30
μ
H
D.U.T.
+18V
0V
Vr
trr/Qrr
Waveform
APT’s products are covered by one or more of U.S.patents 4,895,810 5,045,903 5,089,434 5,182,234 5,019,522
5,262,336 6,503,786 5,256,583 4,748,103 5,283,202 5,231,474 5,434,095 5,528,058 and foreign patents. US and Foreign patents pending. All Rights Reserved.
TO-264 (LCT) Package Outline
19.51 (.768)
19.81 (.780)
25.48 (1.003)
2.29 (.090)
0.76 (.030)
2.79 (.110)
3.10 (.122)
4.60 (.181)
1.80 (.071)
2.59 (.102)
0.48 (.019)
Common Cathode
Anode 2
Anode 1
Dimensions in Millimeters and (Inches)
C
2.29 (.090)
5.79 (.228)
5.45 (.215) BSC
2-Plcs.
e1 SAC: Tin, Silver, Copper
