15
Table 16. Calibration constants for External Calibration Option (2-Wire Address A2h)
Address
# Bytes
Name
Description
Content
56-59
4
Rx_PWR(4)
Single precision floating point calibration data -Rx optical power. Bit 7
of byte 56 is MSB. Bit 0 of byte 59 is LSB.
0
60-63
4
Rx_PWR(3)
Single precision floating point calibration data -Rx optical power. Bit 7
of byte 60 is MSB. Bit 0 of byte 63 is LSB.
0
64-67
4
Rx_PWR(2)
Single precision floating point calibration data, Rx optical power. Bit 7
of byte 64 is MSB, bit 0 of byte 67 is LSB.
0
68-71
4
Rx_PWR(1)
Single precision floating point calibration data, Rx optical power. Bit 7
of byte 68 is MSB, bit 0 of byte 71 is LSB.
1
72-75
4
Rx_PWR(0)
Single precision floating point calibration data, Rx optical power. Bit 7
of byte 72 is MSB, bit 0 of byte 75 is LSB.
0
76-77
2
Tx_I(Slope)
Fixed decimal (unsigned) calibration data, laser bias current. Bit 7 of
byte 76 is MSB, bit 0 of byte 77 is LSB.
1
78-79
2
Tx_I(Offset)
Fixed decimal (signed two’s complement) calibration data, laser bias
current. Bit 7 of byte 78 is MSB, bit 0 of byte 79 is LSB.
0
80-81
2
Tx_PWR(Slope)
Fixed decimal (unsigned) calibration data, transmitter coupled output
power. Bit 7 of byte 80 is MSB, bit 0 of byte 81 is LSB.
1
82-83
2
Tx_PWR(Offset)
Fixed decimal (signed two’s complement) calibration data, transmitter
coupled output power. Bit 7 of byte 82 is MSB, bit 0 of byte 83 is LSB.
0
84-85
2
T(Slope)
Fixed decimal (unsigned) calibration data, internal module tempera-
ture. Bit 7 of byte 84 is MSB, bit 0 of byte 85 is LSB.
1
86-87
2
T(Offset)
Fixed decimal (signed two’s complement) calibration data, internal
module temperature. Bit 7 of byte 86 is MSB, bit 0 of byte 87 is LSB.
0
88-89
2
V(Slope)
Fixed decimal (unsigned) calibration data, internal module supply
voltage. Bit 7 of byte 88 is MSB, bit 0 of byte 89 is LSB.
1
90-91
2
V(Offset)
Fixed decimal (signed two’s complement) calibration data, internal
module supply voltage. Bit 7 of byte 90 is MSB. Bit 0 of byte 91 is LSB.
0
92-94
3
Reserved
———
95
1
Checksum
Byte 95 contains the low order 8 bits of the sumof bytes 0-94.
———
