14
Byte# Data
Byte#
Data
Decimal Hex
Notes
Decimal Hex
Notes
0
03
SFP physical device
37
00
Hex Byte of Vendor OUI[4]
1
04
SFP function defined by serial ID only
38
30
Hex Byte of Vendor OUI[4]
2
07
LC optical connector
39
D3
Hex Byte of Vendor OUI[4]
3
00
40
41
“A” - Vendor Part Number ASCII character
4
00
41
46
“F” - Vendor Part Number ASCII character
5
00
42
“B” - Vendor Part Number ASCII character
6
00
43
52
“R” - Vendor Part Number ASCII character
7
20
Intermediate distance (per FC-PI)
44
2D
“-” - Vendor Part Number ASCII character
8
40
Shortwave laser without OFC (open fiber control)
45
35
“5” - Vendor Part Number ASCII character
9
0C
Multi-mode 50 m and 62.5 m optical media
46
37
“7” - Vendor Part Number ASCII character
10
15
100, 200 & 400 Mbytes/sec FC-PI speed[1]
47
52
“R” - Vendor Part Number ASCII character
11
01
Compatible with 8B/10B encoded data
48
35
“5” - Vendor Part Number ASCII character
12
2B
4300 MBit/sec nominal bit rate (4.25 Gbit/s)
49
41
“A” - Vendor Part Number ASCII character
13
00
50
45
“E” - Vendor Part Number ASCII character
14
00
51
5A
“Z” - Vendor Part Number ASCII character
15
00
52
20
“ ” - Vendor Part Number ASCII character
16
0F
150 m of 50/125 m fiber @ 4.25GBit/sec[2]
53
20
“ ” - Vendor Part Number ASCII character
17
07
70 m of 62.5/125 m fiber @ 4.25GBit/sec[3]
54
20
“ ” - Vendor Part Number ASCII character
18
00
55
20
“ ” - Vendor Part Number ASCII character
19
00
56
20
“ ” - Vendor Part Number ASCII character
20
41
“A” - Vendor Name ASCII character
57
20
“ ” - Vendor Part Number ASCII character
21
56
“V” - Vendor Name ASCII character
58
20
“ ” - Vendor Part Number ASCII character
22
41
“A” - Vendor Name ASCII character
59
20
“ ” - Vendor Part Number ASCII character
23
47
“G” - Vendor Name ASCII character
60
03
Hex Byte of Laser Wavelength[5]
24
4F
“0” - Vendor Name ASCII character
61
52
Hex Byte of Laser Wavelength[5]
25
20
“ ” - Vendor Name ASCII character
62
00
26
20
“ ” - Vendor Name ASCII character
63
Checksum for Bytes 0-62[6]
27
20
“ ” - Vendor Name ASCII character
64
00
28
20
“ ” - Vendor Name ASCII character
65
3A
Hardware SFP TX_DISABLE, TX_FAULT,
& RX_LOS
29
20
“ ” - Vendor Name ASCII character
66
00
30
20
“ ” - Vendor Name ASCII character
67
00
31
20
“ ” - Vendor Name ASCII character
68-83
Vendor Serial Number ASCII characters[7]
32
20
“ ” - Vendor Name ASCII character
84-91
Vendor Date Code ASCII characters[8]
33
20
“ ” - Vendor Name ASCII character
92
68
Digital Diagnostics, Internal Cal, Rx Pwr
Avg
34
20
“ ” - Vendor Name ASCII character
93
F0
A/W, Soft SFP TX_DISABLE, TX_FAULT,
& RX_LOS
35
20
“ ” - Vendor Name ASCII character
94
01
SFF-8472 Compliance to revision 9.3
36
00
95
Checksum for Bytes 64-94[6]
96 - 255 00
Notes:
1. FC-PI speed 100 MBytes/sec is a serial bit rate of 1.0625 GBit/sec. 200 MBytes/sec is a serial bit rate of 2.125 GBit/sec. 400 MBytes/sec is a serial
bit rate of 4.25 GBit/sec.
2. Link distance with 50/125 m cable at 1.0625 GBit/sec is 500 m. Link distance at 2.125 GBit/sec is 300 m.
3. Link distance with 62.5/125 m cable at 1.0625 GBit/sec is 300 m. Link distance with 62.5/125 m cable at 2.125 GBit/sec is 150 m.
4. The IEEE Organizationally Unique Identifier (OUI) assigned to Avago Technologies is 00-30-D3 (3 bytes of hex).
5. Laser wavelength is represented in 16 unsigned bits. The hex representation of 850 (nm) is 0352.
6. Addresses 63 and 95 are checksums calculated (per SFF-8472 and SFF-8074) and stored prior to product shipment.
7. Addresses 68-83 specify the AFBR-57R5AEZ ASCII serial number and will vary on a per unit basis.
8. Addresses 84-91 specify the AFBR-57R5AEZ ASCII date code and will vary on a per date code basis.
Table12.EEPROMSerialIDMemoryContents–ConventionalSFPMemory(AddressA0h)
