參數資料
| 型號： | ADG3249BRJ-R2 |
| 廠商： | Analog Devices Inc |
| 文件頁數： | 7/12頁 |
| 文件大小： | 0K |
| 描述： | IC MUX/DEMUX 2X1 SOT23-8 |
| 產品培訓模塊： | iCMOS™ Switches and Multiplexers for Data Acquisition Switch Fundamentals |
| 標準包裝： | 1 |
| 功能： | 多路復用器/多路分解器 |
| 電路： | 1 x 2:1 |
| 導通狀態電阻： | 12 歐姆 |
| 電壓電源： | 單電源 |
| 電壓 - 電源，單路/雙路(±)： | 2.3 V ~ 3.6 V |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | SOT-23-8 |
| 供應商設備封裝： | SOT-23-8 |
| 包裝： | 剪切帶 (CT) |
| 其它名稱： | ADG3249BRJ-R2CT |
REV. 0
–4–
ADG3249
TERMINOLOGY
VCC
Positive Power Supply Voltage.
GND
Ground (0 V) Reference.
VINH
Minimum Input Voltage for Logic 1.
VINL
Maximum Input Voltage for Logic 0.
II
Input Leakage Current at the Control Inputs.
IOZ
OFF State Leakage Current. It is the maximum leakage current at the switch pin in the OFF state.
IOL
ON State Leakage Current. It is the maximum leakage current at the switch pin in the ON state.
VP
Maximum Pass Voltage. The maximum pass voltage relates to the clamped output voltage of an NMOS device when
the switch input voltage is equal to the supply voltage.
RON
Ohmic Resistance Offered by a Switch in the ON State. It is measured at a given voltage by forcing a specified
amount of current through the switch.
RON
ON Resistance Match between Any Two Channels, i.e., RON max to RON min.
CX OFF
OFF Switch Capacitance.
CX ON
ON Switch Capacitance.
CIN, CSEL, CEN
Control Input Capacitance. This consists of IN,
SEL, and EN.
ICC
Quiescent Power Supply Current. This current represents the leakage current between the VCC and ground pins.
It is measured when all control inputs are at a logic high or low level and the switches are OFF.
ICC
Extra power supply current component for the
EN control input when the input is not driven at the supplies.
tPLH, tPHL
Data Propagation Delay through the Switch in the ON State. Propagation delay is related to the RC time constant
RON
× CL, where CL is the load capacitance.
tPZH, tPZL
Bus Enable Times. These are the times taken to cross the VT voltage at the switch output when the switch turns on
in response to the control signal,
EN.
tPHZ, tPLZ
Bus Disable Times. These are the time taken to place the switch in the high impedance OFF state in response to the
control signal. They are measured as the time taken for the output voltage to change by V from the original
quiescent level, with reference to the logic level transition at the control input. (Refer to Figure 3 for enable
and disable times.)
tBBM
On or Off Time. Measured between the 90% points of both switches when switching fom one to another.
tTRANS
Time taken to switch from one channel to the other, measured from 50% of the IN signal to 90% of the
OUT signal.
Max Data Rate
Maximum Rate at which Data Can Be Passed through the Switch.
Channel Jitter
Peak-to-Peak Value of the Sum of the Deterministic and Random Jitter of the Switch Channel.
