5
Electrical Characteristics for WCDMA Mode (Band9)
- Conditions: Vcc=3.4V, Ven=2.6V, T=25°, Zin/Zout=50ohm
- Signal Configuration: 3GPP (DPCCH + 1DPDCH) Up-Link unless specified otherwise.
Characteristics
Condition
Min.
Typ.
Max.
Unit
Operating Frequency Range
1750
–
1785
MHz
Gain
High Power Mode, Pout=28.0dBm
24.5
28.5
dB
Mid Power Mode, Pout=17dBm
16.5
20.5
dB
Bypass Mode, Pout=8dBm
9
13.0
dB
Power Added Efficiency
High Power Mode, Pout=28.0dBm
33.1
39.4
%
Mid Power Mode, Pout=17dBm
14.6
19.5
%
Bypass Mode, Pout=8dBm
8.8
14.1
%
Total Supply Current
High Power Mode, Pout=28.0dBm
470
560
mA
Mid Power Mode, Pout=17dBm
75
100
mA
Bypass Mode, Pout=8dBm
12.5
20
mA
Quiescent Current
High Power Mode
75
100
125
mA
Mid Power Mode
15
25
40
mA
Bypass Mode
1
3
5
mA
Enable Current
High Power Mode
10
25
A
Mid Power Mode
10
25
A
Bypass Mode
10
25
A
Mode Control Current
Mid Power Mode
5
25
A
Bypass Mode
5
25
A
Bypass Control Current
Bypass
5
25
A
Total Current in Power-down mode
Ven=0V, Vmode=0V, Vbp=0V
5
A
Adjacent Channel
Leakage Ratio
5 MHz offset
10 MHz offset
High Power Mode, Pout=28.0dBm
-42
-52
-36
-46
dBc
5 MHz offset
10 MHz offset
High Power Mode, Pout=27.0dBm
(HSDPA, HSUPA MPR=0dB)
-39
-51
-36
-46
dBc
5 MHz offset
10 MHz offset
Mid Power Mode, Pout=17dBm
-43
-57
-36
-46
dBc
5 MHz offset
10 MHz offset
Mid Power Mode, Pout=16dBm
(HSDPA, HSUPA MPR=0dB)
-41
-57
-36
-46
dBc
5 MHz offset
10 MHz offset
Bypass Mode, Pout=8dBm
-44
-54
-36
-46
dBc
5 MHz offset
10 MHz offset
Bypass Mode, Pout=7dBm
(HSDPA, HSUPA MPR=0dB)
-43
-53
-36
-46
dBc
Harmonic
Suppression
Second
Third
High Power Mode, Pout=28.0dBm
-41
-62
-35
-40
dBc
