參數資料
型號： 87568-7
元件分類： 電路板相疊連接器
英文描述： 22 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER
文件頁數： 3/3頁
文件大?。?/td> 97K
代理商： 87568-7
Searchable Features:
Brand:
AMP
Header Type:
Shrouded
No. of Rows:
Dual
No. of Positions:
10
Profile:
Standard
Shrouded End
Dimension (mm [in]):
3.81 [.150]
Mount Angle:
Right Angle
PCB Retention
Feature:
Without
Surface Mount
Compatible:
No
Contact Mating Area
Plating:
Bright Tin
Board Standoff:
Without
Mounting Ears:
Without
Panel Attachment:
No
Mating Connector
Lock:
Without
High Temperature
Housing:
No
Housing Style:
3-Sided
High Speed Serial
Data Connector:
No
Termination Post
Length (mm [in]):
3.18 [.125]
Other Properties:
Centerline
Spacing (mm [in]):
2.54 x 2.54 [.100 x
.100]
Post Size (mm
[in]):
0.64 [.025] Sq.
Mating Post
Length (mm [in]):
8.08 [.318]
Contact Material:
Phosphor Bronze
Solder Tail
Plating:
Bright Tin
Housing Material:
Thermoplastic
Housing Color:
Black
Housing
Flammability
Rating:
UL 94V-0
Part Details for P/N: 87568-1
file:////sprint/bitting1/imaging/BITTING/HTML_Club/20020226/02252002/AMPI/02252002/163068.htm (2 of 2) [01-3ar-2002 5:59:43 PM]
