參數資料
| 型號： | 2SC4197 |
| 廠商： | Hitachi,Ltd. |
| 英文描述： | Silicon NPN Epitaxial |
| 中文描述： | npn型硅外延 |
| 文件頁數： | 7/10頁 |
| 文件大小： | 56K |
| 代理商： | 2SC4197 |
2SC4197
7
Y Parameters
(Emitter Common)
Test Condition
V
CE
= 5 V, I
C
= 5 mA
Freq.
Yie (mS)
Yfe (mS)
Yre (mS)
Yoe (mS)
(MHz)
REAL
IMAG.
REAL
IMAG.
REAL
IMAG.
REAL
IMAG.
100
2.663
5.357
161.804
–34.193
–0.002
–0.425
0.055
0.627
200
5.558
10.174
147.899
–63.499
–0.012
–0.880
0.025
1.270
300
9.651
13.450
125.634
–87.205
–0.041
–1.354
0.026
2.024
400
14.160
15.066
102.261
–102.289
–0.093
–1.820
0.044
2.772
500
18.753
15.624
80.041
–110.827
–0.150
–2.309
0.048
3.510
600
23.019
14.727
57.826
–114.923
–0.214
–2.798
0.124
4.301
700
26.444
13.908
40.437
–113.783
–0.263
–3.305
0.211
4.964
800
29.378
12.040
24.049
–111.316
–0.379
–3.822
0.268
5.828
900
31.931
9.960
10.602
–106.726
–0.466
–4.371
0.407
6.578
1000
33.671
7.667
–0.922
–101.485
–0.586
–4.913
0.524
7.381
Test Condition
V
CE
= 5 V, I
C
= 10 mA
Freq.
Yie (mS)
Yfe (mS)
Yre (mS)
Yoe (mS)
(MHz)
REAL
IMAG.
REAL
IMAG.
REAL
IMAG.
REAL
IMAG.
100
5.212
6.660
273.909
–97.915
–0.002
–0.430
0.029
0.527
200
10.124
10.767
208.225
–154.453
–0.015
–0.876
0.011
1.307
300
15.094
11.730
141.558
–172.198
–0.044
–1.347
0.047
2.035
400
18.933
10.991
93.174
–169.490
–0.089
–1.817
0.064
2.735
500
21.811
10.074
58.181
–158.809
–0.133
–2.299
0.096
3.501
600
23.927
8.389
32.829
–146.284
–0.195
–2.785
0.173
4.226
700
25.848
7.170
15.188
–134.592
–0.276
–3.302
0.224
5.010
800
26.851
5.955
2.733
–123.322
–0.353
–3.808
0.282
5.760
900
28.097
4.633
–7.642
–113.209
–0.443
–4.375
0.394
6.551
1000
28.686
3.829
–13.979
–104.651
–0.523
–4.908
0.466
7.215
